60*60*10mm Generator Cooling Fan

60*60*10mm Generator Cooling Fan thumbnail-1
60*60*10mm Generator Cooling Fan photo-1
US$ 1.5 - 5 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Electric Current Type:
DC
Mounting:
Other, cooling fan
Blade Material:
Plastic
Contact Supplier Request Quote Chat Now
Shenzhen Topfan Technology Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Electric Current Type DC
Mounting Other, cooling fan
Blade Material Plastic
Place of Origin Guangdong, China
Brand Name OEM/ODM
Model Number YM0506PFS(B)3
Voltage 12V
Power 1.00W
Air Volume 13.20CFM
Speed 3000RPM
Certification Other, UL, CE, ISO9000, UL ,CE, RoHS, TUV

Specifications

cooling fan (60*60*10mm):
motor protection
high static pressure
low noise and long life expectancy
good quality and price.

60*60*10mm generator cooling fan

General Specifications:

Frame

plastic(UL94v-0)

Impeller

plastic(UL94v-0)

Bearing type

Sleeve Bearing and Dual Ball Bearing

Leadwire

UL1007AWG#26 or Equivalent (+):Red(-):Black

Motor

Impedance Protected and Reverse Polarity Protected

Voltage

5V/12V/24V

Certification

ISO9000, UL ,CE, RoHS, TUV



Expected Life:

1.Ball Bearing 50,000 hours(40°c)

2.Sleeve Bearing 30,000 hours(40°c)



Allowable Ambient Temperature Range

1.-10°c~+70°c (Operating)

2.-40°c~+70°c (Storage)

3.(non-condensing environment)



60*60*10mm generator cooling fan60*60*10mm generator cooling fan

Specifications:

Size(mm) Model Rated voltage (v)      Operating Voltage Range(v)    Current amp    (Amp) Rated Input Power  Watt Speed (rpm)  Max air Flow(CFM) Max Static Pressure (Inch-H2o) Noise Leve (dB-A) Weight (g)
 50 X 50 X 20 YM0505PKS(B)1 5 3.5 to 5.5 0.24 1.2 4700 13.2 0.13 27 32
  YM0505PKS(B)2 5 3.5 to 5.5 0.19 0.95 4300 11.8 0.09 26 32
  YM0505PKS(B)3 5 3.5 to 5.5 0.15 0.75 4000 10.98 0.08 25 32
  YM1205PKS(B)1 12 7.0 to 13.8 0.13 1.56 5500 15.51 0.18 33 32
  YM1205PKS(B)2 12 7.0 to 13.8 0.11 1.32 5000 13.95 0.14 29 32
  YM1205PKS(B)3 12 7.0 to 13.8 0.08 0.96 4500 12.35 0.1 26 32
  YM2405PKS(B)1 24 14.0 to 27.6 0.09 2.16 5500 15.51 0.18 33 32
  YM2405PKS(B)2 24 14.0 to 27.6 0.07 1.68 5000 13.95 0.14 29 32
  YM2405PKS(B)3 24 14.0 to 27.6 0.06 1.44 4500 12.35 0.1 26 32
