Ventilation Fans 92 mm

Ventilation Fans 92 mm thumbnail-1
Ventilation Fans 92 mm thumbnail-2
Ventilation Fans 92 mm photo-1
Ventilation Fans 92 mm photo-2
US$ 1 - 8 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Electric Current Type:
DC
Mounting:
Other, Built-in cooling fan
Blade Material:
Plastic
Contact Supplier Request Quote Chat Now
Shenzhen Topfan Technology Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SZ
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Electric Current Type DC
Mounting Other, Built-in cooling fan
Blade Material Plastic
Place of Origin Guangdong, China
Brand Name topfan
Model Number YM4809PLB3
Voltage 48V
Power 8.16W
Air Volume 98.00CFM
Speed 3700rpm
Certification CCC, CE, ROHS, UL, CE, UL, Other, CCC, CE, ROHS, UL, CE, UL, TUV, RoHS

Discription of YM4809PLB3 smart ac fan 92 X 92 X 32mm:



1. Expexted life

1). Ball Bearing  50,000 hours(400C)



2. Allowable Ambient Temperature Range:

1). -100C~+700C (Operating)

2). -400C~+700C (Storage)

3). non-condensing environment



 General Specification

Model YM4809PLB3
Frame Plastic(UL94V-0)
Impeller Plastic(UL94V-0)
Bearing Ball Bual Ball Bearing
Leadwire UL1007AWG24 or Equivalent (+): Red (-0 Black
Motor Impedance Protected and Reverse Polarity Protected



Product Features



Size(mm) Model Rated voltage (v)      Operating Voltage Range(v)    Current amp    (Amp) Rated Input Power  Watt Speed (rpm)  Max air Flow(CFM) Max Static Pressure (Inch-H2o) Noise Leve (dB-A) Weight (g)
92 *92 * 32 YM4809PLB3 48.00 28.0 to 56.0 0.17 8.16 3700 98 0.37 45.00 150.00



Our Series of 92 X 92 X 32mm



Size(mm) Model Rated voltage (v)      Operating Voltage Range(v)    Current amp    (Amp) Rated Input Power  Watt Speed (rpm)  Max air Flow(CFM) Max Static Pressure (Inch-H2o) Noise Leve (dB-A) Weight (g)
92 *92 * 32 YM1209PLB1 12.00 7.0 to 13.8 1.07 12.84 4700 117 0.58 50.00 150.00
  YM1209PLB2 12.00 7.0 to 13.8 0.88 10.56 4200 107 0.49 48.00 150.00
  YM1209PLB3 12.00 7.0 to 13.8 0.69 8.28 3700 98 0.37 45.00 150.00
  YM2409PLB1 24.00 14.0 to 27.6 0.53 12.72 4700 117 0.58 50.00 150.00
  YM2409PLB2 24.00 14.0 to 27.6 0.44 10.56 4200 107 0.49 48.00 150.00
  YM2409PLB3 24.00 14.0 to 27.6 0.35 8.40 3700 98 0.37 45.00 150.00
  YM4809PLB1 48.00 28.0 to 56.0 0.27 12.96 4700 117 0.58 50.00 150.00
  YM4809PLB2 48.00 28.0 to 56.0 0.22 10.56 4200 107 0.49 48.00 150.00
  YM4809PLB3 48.00 28.0 to 56.0 0.17 8.16 3700 98 0.37 45.00 150.00
