Quick Details
| Application: | Laser Cutting,cnc laser cutting machine price |
Condition: | New |
Laser Type: | CO2,CO2 Sealed Laser Tube , 10.6μm |
| Applicable Material: | Acrylic,Glass,Leather,MDF,Paper,plastic,Plexiglax,Plywood,Wood |
Cutting Thickness: | 0-20 |
Cutting Area: | 1300*900 |
| Cutting Speed: | 0-40000mm/min |
CNC or Not: | Yes |
Cooling Mode: | Water Cooling |
| Control Software: | laser work V8,Laser workV8 |
Graphic Format Supported: | AI,PLT,DST,DXP,DST PLT BMP DXF DWG AI LAS,etc |
Place of Origin: | Shandong China (Mainland) |
| Brand Name: | Bodor |
Model Number: | BCL1309X cnc laser cutting machine price |
Certification: | CE,SGS |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Warranty: | 2 years |
Working area: | 1300*900mm/100*600mm |
| Laser power: | 60W/80W/100W |
Cooling way: | Water cooling |
Power Supply: | AC110V/220V+10%,50HZ/60HZ |
| Drive motor: | Stepper motor |
Packaging & Delivery
| Packaging Detail: | wooden case for cnc laser cutting machine price |
| Delivery Detail: | 7-15 working days |
Specifications
cnc laser cutting machine price 1 high speed,high accuracy 2 FDA CE certification 3. 2 years warranty 4. Laser work V8 soft
cnc laser cutting machine price
Main Features
1. X&Y axis with HIWIN high accuracy square rail, perfect performance.
2. Only manufacturer adopts square tube framework machine body 40%higher than simple iron sheet structure,never distortion.
Prevents machine from quivering and resonance during long time work.
3. High efficiency tube with stable laser path, life time reaches to 10000 hours.
4. Red cross point offers highest accuracy position.
5. Humanized and modern design makes work happy, safe and easy.
6. Transparent acrylic watching door, easy checking work process.
7. Professional motion control card offers continue fast curve cutting together with shortest path selection. Shorten work time.
Technical Parameters
Model |
BCL1006X | BCL1309X | BCL1610XH | BCL1812XH | Option |
| Working Area | 1000*600mm | 1300*900mm | 1600*1000mm | 1800*1200mm | According to Demands |
| Laser Power | 60w/80w/100w/130w//150w | ||||
| Laser Type | CO2 Sealed Laser Tube , 10.6μm | ||||
| Cooling Type | Water Cooling | ||||
| Engraving Speed | 0-60000mm/min | ||||
| Cutting Speed | 0-40000mm/min | ||||
| Laser Output Control | 0-100% set by software | ||||
| Min. Engraving Size | Chinese: 2.0mm*2.0mm, English Letter: 1.0mm*1.0mm | ||||
| Highest Scanning Precision | 4000DPI | ||||
| Locating Accuracy | ≤+0.01mm | ||||
| Controlling Software | DSP Control System | ||||
| Graphic Format Supported | DST PLT BMP DXF DWG AI LAS,etc | ||||
| Compatible Software | CORELDRAW,PHOTOSHOP, AUTOCAD,TAJIMA,etc. | ||||
| Color Separation | Yes | ||||
| Drive System | High-precision 3-phase Stepper Motor | ||||
| Auxiliary Equipments | Exhaust Fan and Air Exhaust Pipe | ||||
| Power Supply | AC110V/220V+10%,50HZ/60HZ | ||||
| Working Environment | Temperature:0-45C,Humidity 5-95%(No Condensate Water) | ||||
Applicable industries Mould industry (construction mould, aviation and navigation mould, wooden mould), advertising, decoration, arts and crafts,
electronics, electric appliances, etc.
Applicable Materials Materials such as acryl, wood planks(light planks,candlenut wood),bamboo ware, double color board, paper, leather, shell,
coconut shell, ox horn, resin animal grease,ABS board, lamp shade, etc.
Machine parts
Machine samples show
Bodor company show
Workshop
Company
outside package: wooden boxes for sea transport or air transport
Jinan Bodor CNC Machine Co.,Ltd was founded in 2002.
In 2008 we formally changed name to Bodor with RMB 10 million registered capital.For 12 years,Bodor laser has always been devoted in studying and manufacturing laser cutting,engraving and marking etc
