Specifications
laser cutting bed for fabric, textile1.2 year warranty
2. high density honeycomb worktable
3. CO2 sealed laser tube
laser cutting bed
| Machine Series | X Series(Optional) | B Series(Optional) | |||||
| Model | BCL1006X | BCL1309X | BCL1610XH | BCL1812XH | BCL 1325B | BCL 1630BH | BCL 1830BH |
| Working Area | 1000*600mm | 1300*900mm | 1600*1000mm | 1800*1200mm | 1300*2500mm | 1600*3000mm | 1800*3000mm |
| Locating Accuracy | ≤+0.01mm | 0.02mm | |||||
| Cutting Speed | 0---40000mm/min | 0—30000mm/min | |||||
| Laser Output Control | 1-100% Set by Software ) | 0-100% adjust freely | |||||
| Drawing Pen Function | add drawing pen function according to demands, then the X axis wide will scale back around 100 mm | ||||||
| Laser Power | 60w/80w/100w/130w/150w | ||||||
| Laser Type | CO2 Sealed Laser Tube ,Water Cooling, 10.6μm | ||||||
| Cooling Type | Water Cooling | ||||||
| Min. Engraving Size | Chinese: 2.0mm*2.0mm, English Letter:1.0mm*1.0mm | ||||||
| Highest Scanning Precision | 4000DPI | ||||||
| Graphic Format Supported | DST PLT BMP DXF AI DSB BMP GIF JPEG PNG ICON CURSOR TIFF TGA PCX WBMP WMF EMF JBG PGX, etc | ||||||
| Color Separation | Yes | ||||||
| Power supply | AC110V/220V+10%,50HZ/60HZ | ||||||
| Drive System | High-precision 3-phase Stepper Motor | ||||||
| Option | Up-down table,Honeycomb platform,Rotary device,Auto-focus Device | ||||||
driver systerm and power supply
inside package: transparent membrane
outside package: wooden boxes for sea transport or air transport
Jinan Bodor CNC Machine Co.,Ltd was founded in 2002.
In 2008 we formally changed name to Bodor with RMB 10 million registered capital.For 12 years,Bodor laser has always been devoted in studying and manufacturing laser cutting,engraving and marking etc
2 year warranty
1. How to choose laser power ?
according to the length of laser tube
| laser power | length of laser tube | outside diameter of laser tube | acrylic cutting | wood cutting | plywood and MDF |
| 40w | 800mm | 50mm | 3mm | 1mm | / |
| 50w | 1000mm | 50mm | 5mm | 3mm | 1mm |
| 60w | 1250mm | 50mm | 8mm | 6mm | 3mm |
| 80w | 1600mm | 60mm | 15mm | 10mm | 6mm |
| 100w | 1650mm | 80+-2mm | 20mm | 12mm | 8mm |
|
W2:rated power90w max power100w |
1200mm | 80mm | 20mm | 12mm | 8mm |
|
W4:rated power120w max power135w |
1400mm | 80mm | 25-30mm | 16mm | 10mm |
|
W6:rated power150w max power170w |
1650mm | 80mm | 30-35mm | 22mm | 14mm |
|
W8:rated power170w max power200w |
1850mm | 90mm | 35-40mm | 24mm | 16mm |
2. What is in package?
machine with laser tube, double faced adhesive tape, path adjusting piece, focus scale, spanner, air pipe, water pipe, fan pipe...
3.What is M serial Packing size and Weight?
4.How to choose work table? Honeycomb table or stainless steel blade table?
For acrylic -we recommend stainless steel work table(blade worktable).
Reason: Acrylic is almost pure in light. Honey comb inside has 6 reflect pieces,when cutting acrylic,honey comb reflect pieces will make laser path reflect back to acrylic material surface.
For paper -we recommend honeycomb work table.
Reason:Honeycomb has flat and comb design ,When working, smoke will be absorbed totally inside to keep paper or leather in cleaning way.
Stainless Steel work table is between Honeycomb and Standard blade design.That is why we offer such workfloor as standard specification.
@What is the maximum diameter three jaw rotary device?
80mm
@How many mm is the up-down table?
160mm
@How can we do if the laser tube is longer the machine length?
RECI W2: Installing lengthened cover on the machine
