Fabric laser cutting machine 1600*1000mm
- 200 Set / Sets per Month
- Qingdao Shanghai Tianjin
- T/T Credit Card
You May Like
-
auto-feeding double head laser cutting machine fabric cutting
-
textile laser cutting machine 1600*1000mm
-
auto-feeding laser cutting machine 1600*1000mm
-
auto-feeding laser cutting machine 1610XH2HA
-
auto-feeding fabric cutting laser cutting machine 1600*1000mm
-
60W 80W laser cutting bed 1730 for fabric, textile
Product Details
Condition | New | Laser Type | CO2 | |
Engraving Area | 1600*1000mm | Engraving Speed | 0-60000mm/min | |
CNC or Not | No | Cooling Mode | Water Cooling | |
Applicable Material | Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Wood | Graphic Format Supported | AI, PLT, DXF, BMP, DST, DWG, LAS, DXP | |
Place of Origin | Shandong, China | Brand Name | bodor | |
Model Number | 1610XH2H(M)A | Dimension(L*W*H) | 1673mm*1130mm*1110mm | |
Certification | CE, SGS, Other, CE, SGS, FDA | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
auto-feeding fabric double head movable laser cutting machine1.2 year warranty
2.double head movable autofeeding for textile
1610 XH2HMA auto-feeding fabric textile double head movable laser cutting machine
1. High-efficiency co2 laser tube 60w/80w/130w/150w/180w
2. Electric up and down working table 160mm
3. Stainless steel hollow working table
4. Red dot cross position system
5.Taiwan HIWIN square rail, high accuracy
6.Transparent acrylic watching door, easy checking work process
7. U flash offline operation
8. Independent laser tube cabinet, protect tube and easy change
Application Material
materials such as acrylic, crystal, plastic, wood planks(light planks,candlenut wood),bamboo ware, double color board, paper, leather, shell, coconut shell, ox horn, resin animal grease, ABS board, ceramic, lamp shade, etc.
Application
Mould industry (construction mould, aviation and navigation mould, wooden mould), advertising, decoration, arts and crafts,
electronics, electric appliances, etc.
Model | BCL1610XH2HA | BCL1610XH2HMA | Option |
Amountof Laser Head | Double-head | Double-head | According to Demands |
Lase Head Adjustment | Manually | Electrically | |
Working Area | 1600*1000mm | 1600*1000mm | |
Laser Power | 60w/80w/100w/130w/150w | ||
Laser Type | CO2 Sealed Laser Tube,10.6μm | ||
Cooling Type | Water Cooling | ||
Max.Moving Speed | 1600mm/s | ||
Max.Working Speed | 1400mm/s | ||
Laser Output Control | 0-100% Set by Software | ||
Min.Character Engraved | Chinese:2.0mm×2.0mm,Englishletter:1.0mm×1.0mm | ||
Highest Scanning Precision | 4000DPI | ||
Locating Accuracy | ≤+0.02mm | ||
Controlling Software | DSP Control System | ||
Graphic Format Supported | DST PLT BMP DXF DWG AI LAS,etc | ||
Compatible Software | CORELDRAW,PHOTOSHOP,AUTOCAD,TAJIMA,etc. | ||
Color Separation | Yes | ||
Drive System | High-precision 3-phase Stepper Motor | ||
Auxiliary Equipments | Exhaust Fan and Smoke Pipe | ||
Power Supply | AC110V/220V+10%,50HZ/60HZ | ||
Working Environment | Temperature0-45°C,Humidity5-95%(No Condensate Water) |
double head mouvable laser cutting machine fabric auto-feeding
blade worktable
driver systerm and power supply
About Bodor
Jinan Bodor CNC Machine Co.,Ltd was founded in 2002.In 2008 we formally changed name to Bodor with RMB 10 million registered capital.For 12 years,Bodor laser has always been devoted in studying and manufacturing laser cutting,engraving and marking etc.
With all Bodor staff persistence and hard working,Bodor laser has developed to a large-scale international manufacturing company.More accuracy,more automatically and higher quality products with intimate after-sales service enables Bodor be the leader of laser industry.Suitable services for customers,2-year warranty products,standard scientific management make bodor earn the best reputation and word-wide trusted customers.
For 12 years,Bodor laser machines cover all Chinese market and also very popular in America,West Europe,South Asian,East Asian etc. More than 80 countries. Bodor lasers will try our best to serve for you suitable laser solutions. Welcome you to join Bodor family,share top laser products and services together with word-wide customers.
Our Customer in Factory
Products series
Our sales team
Our Package Advantage:
1.Our wooden case is after fumigation treatment.Needn’t timber inspection,saving shipping time.
2.All the spare parts of the machine were covered by some soft materials,mainly using pearl wool.
Avoiding all damages that could happen in the delivery process.Then we’ll covered plastic wrap out it tightly,make sure intact of the covered soft materials,also avoiding Waterproof and rust proof.
3.The outmost is wooden case with fixed formwork.
4.The bottom of the wooden case has firm iron jack,convenient to Handling and transport.
We offer
- Sea Transportation
- Land Transportation
- Air Transportation
1. How to choose laser power ?
according to the length of laser tube
laser power | length of laser tube | outside diameter of laser tube | acrylic cutting | wood cutting | plywood and MDF |
40w | 800mm | 50mm | 3mm | 1mm | / |
50w | 1000mm | 50mm | 5mm | 3mm | 1mm |
60w | 1250mm | 50mm | 8mm | 6mm | 3mm |
80w | 1600mm | 60mm | 15mm | 10mm | 6mm |
100w | 1650mm | 80+-2mm | 20mm | 12mm | 8mm |
W2:rated power90w max power100w | 1200mm | 80mm | 20mm | 12mm | 8mm |
W4:rated power120w max power135w | 1400mm | 80mm | 25-30mm | 16mm | 10mm |
W6:rated power150w max power170w | 1650mm | 80mm | 30-35mm | 22mm | 14mm |
W8:rated power170w max power200w | 1850mm | 90mm | 35-40mm | 24mm | 16mm |
2. What is in package?
machine with laser tube, double faced adhesive tape, path adjusting piece, focus scale, spanner, air pipe, water pipe, fan pipe...
3.What is M serial Packing size and Weight?
4.How to choose work table? Honeycomb table or stainless steel blade table?
For acrylic -we recommend stainless steel work table(blade worktable).
Reason: Acrylic is almost pure in light. Honey comb inside has 6 reflect pieces,when cutting acrylic,honey comb reflect pieces will make laser path reflect back to acrylic material surface.
For paper -we recommend honeycomb work table.
Reason:Honeycomb has flat and comb design ,When working, smoke will be absorbed totally inside to keep paper or leather in cleaning way.
Stainless Steel work table is between Honeycomb and Standard blade design.That is why we offer such workfloor as standard specification.
@What is the maximum diameter three jaw rotary device?
80mm
@How many mm is the up-down table?
160mm
@How can we do if the laser tube is longer the machine length?
RECI W2: Installing lengthened cover on the machine
