DPB Flat Plate Hard Blister Packing Machine for Tablet
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Medical, Other, Medical, Machinery & Hardware, medical
Automatic Grade:
Automatic
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Application
Medical, Other, Medical, Machinery & Hardware, medical
Automatic Grade
Automatic
Driven Type
Mechanical
Voltage
380V,220HZ
Power
6.2KW
Place of Origin
Zhejiang, China
Brand Name
Shenghe
Model Number
DPB-250E
Dimension(L*W*H)
L3000xw730xh1600 mm
Weight
1600KG
Warranty
One year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Eye marking sealing device with sensor trace can be added for option. Plexiglas cover can be added for option.Flat Plate Auto Hard Blister Packaging Machine
1,It can optional add opposite sealing device with cursor trace.
2,It can optional Plexiglas Cover.
3,It can optional add ink-jet printer.
Main Technical Parameters:
| Cutting Frequency(Times/min) | 6-50 |
| Production Capacity(ten thous pics/h) | 3.5-23 |
| Max Forming Areas And Depth(mm) | 240×150×26(standard 240×150×14) |
| Stroke(mm) | 40-160 (Can Be Lengthened To 180mm As User's Requirements) |
| Standard Plate(mm) | 80×57(Can Be Manufactured As User's Requirements) |
| Air Pressure(Mpa) | 0.4-0.6 |
| Air Supply | ≥0.3m3/min |
| Total Power | 380V/220V 50Hz 6.2kw |
| Main Motor Power (KW) | 1.5 |
| PVC Hard Pieces(mm) | 0.15-0.5×250 |
| PTP Aluminum Foil(mm) | 0.02-0.035×250 |
| Dialysis Paper(mm) | 50-100g×250 |
| Mould Cooling | Tap Water Or Circulating Water |
| Overall Dimensions(mm) | 3000×730×1600(L×W×H) |
| Weight(kg) | 1600 |
