Keyland Oil Heaing Vacuum Laminating Flatbed Solar Panel
- 3000 Set / Sets per Month
- Shanghai/Be appointed
- T/T L/C D/P D/A
You May Like
-
Best Selling China Solar Panel Laminator Machine
-
Solar panel assembly line,solar module assembly machine
-
Keyland Solar Laminating Machine Semi-automatic for Solar Cell
-
Keyland EVA Glass Laminating Machine for Solar Panel Laminating
-
2.2x1.1m/2.2x2.2m laminating machine semi-automatic for solar cell
-
Keyland Solar Panel Laminator Manual
Product Details
Place of Origin | Hubei, China | Brand Name | Keyland/OEM | |
Model Number | KL Solar Panel Laminating Machine |
International Transport Plywood Package
Product Description
Specifications
Vacuum Laminating Flatbed Solar Panel1.Control by panel
2.Oil-heated
3.High vacuum
4.Easy to operate
Keyland Oil Heaing Vacuum Laminating Flatbed Solar Panel
for Small and big Solar Module Laminating
Solar module/cell laminating area:
2200mm*1100mm (Semi-automatic type)
2200mm*2200mm(Semi-automatic typ
2200mm*3600mm( full-automatic type)
Solar Panel Laminating Machine to laminating glass, EVA (Ethylene Vinyl Acetate Sheet), solar cell and back sheet.
Spec. of Solar Panel Laminating Machine :
Power:AC380V 3 Phase five line | |
Mode of heating | Oil |
Degree of vacuum | 200----20Pa |
Way of temperature control | PLC Intelligent Temperature Control |
Laminated cavity height | 20mm |
Compressed air pressure | 0.6----1.0MPa |
Evacuation time up to operating pressure | 5----6 minutes |
Control way | Touch screen |
Control Method | AUTO/MAN |
Lid height | Max 500mm |
Temperature control precision | ≤±1°C |
Temperature uniformity | ±1.5°C |
Compressed air flow | 0.42-0.8m³/min |
Laminating time | 2----4 minutes |
Solar Panel Laminating Machine 's Spec.
Model | Laminating area(mm) | Solar module power (W) | Laminating QTY | Production capacity per year (MW) |
KL-1122 |
1100*2200 | 160w |
1 set | 2.6 |
200w | 3.2 | |||
230w | 3.8 | |||
270w | 4.4 | |||
KL-2222 |
2200*2200 | 160w | 2 sets
| 5.2 |
200w | 6.4 | |||
230w | 7.5 | |||
270w | 8.7 |
*The production capacity is based on 20 working hours per day in 300days (just for reference)
Character of Solar Panel Laminating Machine :
1. Mode of heating:High temperature thermal oil heating,Intelligent PID Control,Good temperature uniformity.
2. Lamination pressure: Adjustable pressure,range0.02----0.1MPa
3. Device structure
- Feed in/ out mode: Platform board for easy access to materials
- Way openings:Hydraulic chain lift arms,high balance,Secure and Reliable.
- Heating plate design:High manganese steel,flatness indeformable,oil by-hole loop structure,fast heat conduction,high heat efficiency.
- Character: Upper flange structural design
- PLC Intelligent Temperature Control
- Intelligent control
- High vacuum indicator
Ready material carrier
Module transfer carrier
Laying upstation
Inspection station
Trimming table
Cleaning table
Our wararnty:
We Manufacture
Solar Panel Laminating Machine Agent Wanted ,
Hope our good quality,competitive price and comprehensive service will help you expand marketing successful.
Also , if you are end-user, more Scheme will be sent with our good price.
Contact Lucia Lv any time, I will reply you ASAP.
