Advertising laser engraving photocopy printing machine 40W 60w 80w 100w mini for sunglass stamp leather jewelry GOOD PRICE
Laser Power:40W 60W 80W 100W 130W 150W
Laser engraving machine is suitable for leather MDF Wood Acrylic and other nonmetal materials 'cutting / Engraving / hollowing.
Details of laser engraving machine :
Model No.KQG |
6040 |
1060 |
1390 |
1318 |
1325 |
1825 |
|
Laser wavelength |
10640nm |
||||||
Laser power |
40W 60W 80W 100W 130W 150W |
||||||
Laser tube |
Reci ,EFR,RF metal laser tube for option |
||||||
Working table |
600*400mm (KQG-6040)1000*600mm (KQG-1060) 1300*900mm (KQG-1390)1300*1800mm (KQG-1318) 1300*2500mm (KQG-1325)1800*2500mm(KQG-1825) |
||||||
Water Chiller |
CW3000 /CW5000 |
||||||
Engraving speed |
≤1000mm/s |
||||||
Repeat positional accuracy |
≤+0.01mm |
||||||
Cutting speed |
≤500mm/s |
||||||
Laser output control |
0-100% set by software |
||||||
Min.engraving size |
1.0*1.0mm |
||||||
Highest scanning precision |
4000DPI |
||||||
Drive system |
stepper Servo motor |
||||||
Interface |
DSP |
||||||
off-line work |
Yes |
||||||
Connect way |
USB OFFLINE |
||||||
Power |
AC110V/220V+10%,50HZ/60HZ |
||||||
Graphic format supported |
DST PLT BMP DXF DWG AI LAS,etc |
||||||
Compatible software |
CORELDRAW,PHOTOSHOP, AUTOCAD,TAJIMA,etc. |
||||||
Cooling way |
Water cooling |
||||||
Exact materials can be used by keyland Laser engraving Machine :
Cutting |
Engraving |
|
Wood |
√ |
√ |
Melamine |
√ |
√ |
Matte Board |
√ |
√ |
Wood veneer |
√ |
√ |
Cork |
√ |
√ |
Corian |
√ |
√ |
Anodized Aluminum |
√ |
|
Painted metals |
√ |
|
Tile |
√ |
|
Plastic |
√ |
√ |
Fiberglass |
√ |
√ |
Acrylic |
√ |
√ |
Fabric |
√ |
√ |
Glass |
√ |
|
Coated metal |
√ |
|
Ceramic |
√ |
|
Delrin |
√ |
√ |
Cloth |
√ |
√ |
Mylar |
√ |
√ |
pressboard |
√ |
√ |
Leather |
√ |
√ |
Rubber |
√ |
√ |
Marble |
√ |
Strong points of laser engraving machine :
1. Laser engraving machine :
Compact & smart unit.Easy to install,operate and maintenance.
*DSP control/USB on& off working
*Software has installed before shipping,all has ajusted
2.Top quality of parts
Imported USA mirrors & lens
Taiwai HIWIN Guide rail
Aluminum working table
Brand motor
3.Longer warranty after service
Lifetime of service & technology supports.
we can tell you how to use till you are being an expert
Keyland 's technology for laser engraving machine :
1. Durable parts and good operating software are be used in our machines.
2. Stronger appearance
3.ocus lens,the focus length is about 50.5/ 63.5 for option,which are suitable for cutting ,engraving and marking.
4.*Auto focus--adjust the working platform and workpiece to a suitable space automatically.
5.*Red pointer --Easy and fast to align.
6.*Z axis-(up down working table)-suitable for thickess of workpiece 's processing.
Auxiliary equipment of laser engraving machine :
1. Blowing nozzle--- Debris being transferred in the process
2. Hydraulic protection,exclusion of dust and smoke.
3. Universal Wheels --easy to move machine
4. Water Chiller---make laser tube longer lifetime.
5. Air pump.fan exhust
Actual photos of machine:
About Keyland
Notice:
Laser engraving machine agents wanted all over the world.
Hope our good quality,comprehensive service and competitive price will help you expand your marketing sucessful.
You can contact me through following way:
CLICK "CONTACT SUPPIER" or "SEND MESSAGE"to send offer to me through alibaba.
To know more about our company new trends ,laser machines' working processing.
