JS SOLAR Poly Solar Panel Solar System 5kw

Name: JS SOLAR Poly Solar Panel Solar System 5kw
Brand: JS SOLAR
SKU: 119259663
Availability: InStock

US$ 0.5 - 0.6 MOQ: 50 Pieces

Key Specifications

Place of Origin:

China

Brand Name:

JS SOLAR

Model Number:

JS250P

Jiangsu Jiasheng Photovoltaic Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name JS SOLAR

Model Number JS250P

Specification Normal

Application Commercial

Output Voltage (V) 36V

Load Power (W) 5kw

Solar Power (W) 250P

Work Time (h) 24 HOURS

Specifications

standard size panel
N0.1 Quality Vs. Cost
covered by UL, TUV, IEC, CSA, CE, MCS, ISO9001/14001
good price and performance

JS SOLAR - TUV CE CEC UL MCS Certified 245, 250, 255W Poly Solar Panel

Product show

Electrical Characteristics

	JS245P	JS250P	JS255P
Optimum Operating Voltage (Vmp)	30.34V	30.48V	30.66V
Optimum Operating Current (Imp)	8.05A	8.24A	8.31A
Open Circuit Voltage (Voc)	36.70V	36.80V	36.9V
Short Circuit Current (Isc)	8.78A	8.85A	8.93A
Maximum Power at STC (Pmax)	245W	250W	255W
Module Efficiency	15.06%	15.37%	15.62%

Operating Module Temperature	-40 °C to +85 °C
Maximum System Voltage	1000 V DC (IEC) / 600V DC (UL)
Maximum Series Fuse Rating	15 A
Power Tolerance	0/+3%

STC: lrradiance 1000 W/m2, module temperature 25 °C, AM=1.5;

Best in Class AAA solar simulator (IEC 60904-9) used, power measurement uncertainty is within +/- 3%

Mechanical Characteristics

Solar Cell	Poly-crystalline silicon 156 × 156 mm (6 inches)
No. of Cells	60(6 × 10)
Dimensions	1640 × 992 × 40mm
Weight	20.0 kgs
Front	Glass 3.2 mm tempered glass
Frame	Anodized aluminium alloy
Junction Box	IP67 rated (3 bypass diodes)
Output Cables	TUV (2Pfg1169:2007), UL 4703, UL444.0 mm2, symmetrical lengths (-) 900mm and (+) 900 mm
Connectors	MC4 compatible
Mechanical load test	5400Pa
Resistance	277g steel ball falls down from 1m height and 60m/s wind

Temperature Characteristics

Nominal Operating Cell Temperature (NOCT)	45±2°C
Temperature Coefficient of Pmax	-0.45 %/°C
Temperature Coefficient of Voc	-0.32 %/°C
Temperature Coefficient of Isc	0.06 %/°C
