Help CenterAntique Color Steel Leveling Machine
Related Products
-
New Type Colored Metal Leveling MachineUS$ 7,897 - 12,895MOQ: 1 Set -
Hot Sales Steel Tile Leveling Roll Forming MachineryUS$ 7,400 - 7,600MOQ: 1 Set
-
Iron Panel Automatic Leveling MachineryNegotiableMOQ: 1 Set
-
Steel Leveling MachineUS$ 1,999 - 4,999MOQ: 1 Set
-
HT Leveling MachineUS$ 1,999 - 4,999MOQ: 1 Set
Specifications
1.HT leveling machine2.Speed: 0-9m/min
3.Color: blue etc
4:Certificate: ISO9001:2000
5.Control by PLC
HT leveling machine
NO. |
Item |
Parameter |
1 |
Thickness of middle plate |
60mm |
2 |
Shaft |
15 |
3 |
Diameter of shaft (solid shaft) |
105mm |
4 |
Material of shaft (solid shaft) |
(high grade) 45# Steel, quenched and tempered treatment,hard chromize coated |
5 |
Drive type of roll forming machine |
drive by chain |
6 |
Chain |
25.4 mm (high grade) |
7 |
Bearing |
6210 (high grade) |
8 |
Reducer |
6# cycloid reducer (high grade) |
9 |
Power of main motor |
7.5KW |
10 |
Voltage |
380V/50Hz/3phase |
11 |
Line speed |
about 0-9 m/min
|
12 |
Feeding width |
0-1250mm |
13 |
Suitable coil thickness |
Max thickness for steel coil is 3.0mm |
14 |
Appearance size of main machine |
1.5m (length)*1.2m (width) *1.2m (height)
|
Picture of machine
Certification of our company
After-sales service:
1.We provide the technical support for whole life of our machines.
2.If buyers need the technician to go abroad ,we will arrange the technician,
but the buyers should take all the cost,including visa,roundtripticket etc.
Note:We can customize the design and fabrication on the
particular type of machine according to the request of custmer.
Feature of our machine:
1. Our machine can use galvanized steel sheet,colored armor plate or aluminum plate as the material plate.
2. Controlling by computer,PL display,operationis easy,running is steadyand reliable,endurable,maintence-free.
3. We can make and design what kinds of roll forming machine according to the request of customers
