80W laser engraving machine with price
Features:
This serial models adopted DSP digital control technology, integrated frmae structure to ensure the work stability. The latest spftware can support auto CAD, CorelDRAW, CAD, CDR and other graphical software, and make it available to directly output pictures. The USB data interface can support heat play & pluy. Quick data transiting without taking up computer resource Chinese & English edition liguid display can make it easy for user to operate. This series of laser engraving and cutting machine adopts high precision step-by-step motor as drive part, utilizes three original straight line guide tracks in axis X and Y imported from Taiwan, uses four pieces of specialized laser lens, and enables the machine speedy and accuracy incisive. The engineering design to the path of rays system improves the regulation accuracy of the flight path of rays and the laser use efficiency. This series of laser cutting and engraving machine is an ideal choice for professional user.
Material:
Wood, paper, leather, cloth, organic glass, resin, acrylic, wollens, plastic, rubber, ceramic, tile, crystal, bowlder, bamboo, non-metal material etc.Cloth embroide fabric toy, fabricture, glove, bag, leather, advertising, decoration, electri product, rubber, acrylic product, middle density, board etc non-metal sheet precision cutting and engraving.
Machine type |
TC-1310 |
X axis traveling |
650*2 |
Y axis traveling |
1000mm |
Laser power |
80w |
Driving method |
High speed stepper motor subdivision drive |
Camera lifting |
25mm |
Engraving area |
1300*1000 |
Overall table area |
1920×1310×1070mm |
Controlling system |
Shenzhen Topwisdom system |
Cutting speed |
0-24000mm/min |
Before and after feeding function |
Yes |
Positioning accuracy |
<0.01mm |
Supported image formats |
BMP,HPGL,PLT,DST,DXF,AI |
Resolution ratio |
1000DPI |
Repositioning accuracy |
=0.05mm |
Minimum shaping characters |
Chinese 2*2mm, English 1.5*1.5mm |
Working speed |
0-800mm/s |
Cooling method |
Forced water cooling and protecting system |
Auxiliary device |
Exhaust fan and a smoke exhaust pipe |
Working voltage |
220V=10% |
Operating temperature |
5.35 °C |
Appication:
Materials such as acryl, wood planks(light planks,candlenut wood),bamboo ware, double color board, paper, leather, shell, coconut shell, ox horn, resin animal grease, ABS board, lamp shade,metal, etc.
Our advantage:
1. We have an experienced engineers team
2. Can support one-to-one service
3.Free Tech Support and User Forum is available.
4. One-year warranty.
Factory photos:
Picture of deliver goods
Shipping Terms
1,EXW
2,FOB SZ
3,CIF+Destination port
4,If you need us to book shipping cargo or not and etc,pls notice us,we are more
pleased to do so.
Payment terms
1,T/T 30%T/T in advance against the order confirmed and pay the balance 70%
against goods ready.
2,Western Union Total amount should be below than 5000 USD,and the bank
handling fee should be responsible for you.
3,L/C We would like to talk details with you if you really need L/C payment term
Picture of certificate-CE/FAD/BV and so on
picture of our team
More detaild you can visit our website or contact with us !
