din1.2738 hot rolled sheet high quality special steel plate
Equivalent Grade |
Chemical Composition(%) |
||||||||
C |
Si |
Mn |
Cr |
Mo |
Ni |
P |
S |
||
China/ GB |
3Cr2MnNiMo/718 |
0.33~0.37 |
0.15~0.35 |
0.8~1 |
1.65~1.75 |
0.4~0.5 |
0.4~0.5 |
|
|
USA/ASTM |
P20+Ni |
0.28~0.4 |
0.2~0.8 |
0.6~1.1 |
1.4~2 |
0.80~1.2 |
0.8~1.2 |
|
|
Germany/DIN |
1.2738 |
0.35~0.45 |
0.2~0.4 |
1.3~1.6 |
1.8~2.1 |
0.15~0.25 |
0.9~1.2 |
≤0.035 |
≤0.035 |
Standard
| GB | ASSAB | DIN | ISO |
| 3Cr2MnNiMo | 718 | 1.2738 | 40CrMnNiMo8-6-4 |
Available Size
| Rolled plate | 12-90mm×610mm×L |
Heat Treatment
| Processing | Temperature ℃ | Hardness |
| Anneal | 690-710 | ≤220HB |
| Quenching | 830-870 | 48-52HRC |
| Tempering | 580-650 | 28-35HRC |
| Characteristics | |||||
| 1.High hardening ability | |||||
| 2.Excellent polishing performance and smoothness |
| Cold Working Die Steels | ||
| CH-1 | D3M | SKD11 |
|
|
|
| Hot Working Die Steel | ||
| 5CrMnMo | 5CrNiMo | H13 |
|
|
|
| Plastic Mould Steel | ||
| P20 | 718 | NAK80 |
|
|
|
1.Who are we?
We are a professional manufacturer mould steel for 9years.
2.What is the minimum order quantity?
Our minimum order is 100 pieces or 3 metric tons.
3.What is the production lead time?
Usually the lead time is 20-30 days after order be confirmed.
But for the exact date,please check with our sales team.
4.Why choose us?
We are the manufacturer so can offer the best quality products and competive price.
5.Any other requirements or questions please contact us.
