Specifications
High conductivityGood corrosion resistance
Excellent elongation
The CCA wire is made up by using pure aluminum wire as core. It adopts the advanced coating and welding technology in the world. Plating copper concentrically on the concentric line of aluminum, realizes metallurgy combination between copper coating and aluminum. Threr will be no falking off during the heat treatment or mechanical workout. the CCA is a best new bimetal wire instead of pure copper wire. Producible scope:t the diameter is from 0.16mm to Φ3.00mm.
Product Fearures: shiny & uniformity unlform copper layer, excellent electrical conductivity, bear bending, good tensile strength, excellent welding and corrosion, with the great light specific gravity, and savings resources of copper.
Main Application: flexible coaxial cable, a variety of audio and video cable,vehicle single cable, network cable,data transmission cables and so on. Can be used in the above cables: cable conductor, braiding and shielding, the single wire conductor and other conductors. Applicable to a variety of electronic components' lead wire, such as capacitors, resistors and so on.
1) Diameter: 0.15 - 3.00mm
3) It is divided into 25% and 8% two kinds according to volume scale of copper layer
4) The DC resistivity at temperature of 20°C is less than 0.02676Ω.mm²/m
5) Its nominal density is 3.32g/cm³ - 3.63g/cm³, it is 35 - 37% of pure copper wire
6) Under the same weight, its length is 2.5 - 2.7 times that of pure copper wire
7) It has become the most common wire used in CATV and other high-frequency conduct cable
8) It is a bimetallic wire with a copper cladding concentrically covering an aluminum core, integrating the beneficial properties of the wonderful conductivity of copper and the light-weight of aluminum.
9) It can be scientifically processed into bare wire , and it is the best material for coaxial cable, computer cable,
telephone cable and shielding cable.
10) The processing method is similar to that of copper wire during cable manufacture.
