Horizontal Boring and Milling machine
- 0 per Month
- Shanghai
- T/T
Product Details
Condition: | New | CNC or Not: | Normal | Place of Origin: | Shaanxi, China |
Brand Name: | Yuanhang | Model Number: | TX611 |
Product Description
Specifications
1.CE,standard2.No.1 quality in the market
3.High quality to price ratio
4.spare parts support
The spindle system features strong rigidity, it's suitable for rough machining and force cutting; hence improve machining efficiency, features long travel, heavy loading. It's mainly used for boring and milling big surface and big case parts. The machine can be used for drilling, boring, lathing, and milling. The machine adopts rectangular guide ways, features strong rigidity and high accuracy. Radial tool holder of facing head on the headstock head for radial machining. Optional digital readout device, reading accuracy 0.01 mm, positioning accuracy 0.05 mm.
Model | Unit | TX611B | TX611C | TX611C/4 | |||
Worktable | |||||||
Table size | mm | 1010x1320 | |||||
Loading of table | Kg | 5000 | |||||
Size of T-slot | Pc-mm | 7-22-125 | |||||
Machining range | |||||||
Travel | X | mm | 850 | 1200 | 1800 | ||
Y | mm | 900 | 900 | 1200 | |||
Z | mm | 1100 | 1100 | 1100 | |||
W (Spindle Axial Travel) | mm | 550 | 550 | 550 | |||
Distance from spindle center to worktable | mm | 5-905 | 5-905 | 5-1205 | |||
Max. boring diameter | mm | 240 | |||||
Max. machining diameter for facing plate | mm | 630 | |||||
Max. drilling diameter | mm | 50 | |||||
Spindle | |||||||
Spindle diameter | mm | Φ110(OptionalΦ130) | |||||
Speed range | rpm | 12-950 | |||||
Spindle speed step |
| 18 steps | |||||
Spindle inner taper |
| Morse no.6(Metric 80) | |||||
Facing plate | |||||||
Diameter of facing plate | mm | Φ550 | |||||
Travel of facing plate | mm | 160 | |||||
Speed range of facing plate | rpm | 4-160 | |||||
Facing plate speed step |
| 16steps | |||||
Feeding | |||||||
Rapid speed | X/Y/Z | mm/min | 1800 | ||||
W (Spindle Axial Travel) | mm/min | 3600 | |||||
Facing plate’s rack | mm/min | 1120 | |||||
Feeding range on spindle box and worktable While spindle rotates one circle | mm | 0.025-8 | |||||
Feeding range on spindle box and worktable While facing plate rotates one circle | mm | 0.075-24 | |||||
Feeding range on rack while facing plate Rotates one circle | mm | 0.05-16 | |||||
Weight of machine | Kg | 12000 | 13500 | 16000 | |||
Total electric capacity | KVA | 35 | 35 | 35 | |||
Size of machine | mm | 5016×2628×2788 | 5016×3149×2788 | 5016×3789×3148 |
