R25 Thread Cross Type Rock Button Bit For Drilling

R25 Thread Cross Type Rock Button Bit For Drilling thumbnail-1
R25 Thread Cross Type Rock Button Bit For Drilling thumbnail-2
R25 Thread Cross Type Rock Button Bit For Drilling photo-1
R25 Thread Cross Type Rock Button Bit For Drilling photo-2
US$ 5 - 100 MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
MIROC
Model Number:
CR-33-R25 to CR-51-R25
Contact Supplier Request Quote Chat Now
KSQ Technologies (Beijing) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name MIROC
Model Number CR-33-R25 to CR-51-R25
Type Other, H-thread Steel Cross Type Bit
Material Tungsten Carbide
Use Well Drilling

Our Company

 KSQ Technologies (Beijing) Co. Ltd. is a diversified enterprise based in Beijing, China, offering a portfolio of products that help contribute to a better bottom line and increase workplace safety for the construction and mining industries. The company caters to medium to large scale clients who are doing projects and capital expansion, as well as to firms who require support with consumable products, maintenance, and repair operations. Our operations are based on the unique expertise of our people and knowledge with customer processes.



Specifications

High grade tungsten carbide inserts

Bit bodies manufactured from high grade steel and processed using state-of-the-art CN



Descripetion

Cross type bit with steel inserts using H25 thread system.

It has a slow penetration rate but it produces a very straight drill hole.

• Steel inserts
• Widely used in dimensional stone industry, drifting and tunneling

Color: Green,Blue or Based on Customer requirements



Material: Tungsten carbide and high strength alloy steel



Processing: CNC milling and proprietary heat treatment process



Type: R25 Cross Type Bit



Product Technical Reference



< R25 Cross Type Bit

Part Number

Product Code and

Brief Description

Bit

Diameter

(mm)

Bit

Diameter

(inch)

Tip Size

 (W x H,

mm)

Front

Flushing

drill holes

Side

Flushing

drill holes

Weight

(kg)
4148300397

CR-33-R25, R25

Cross Type Bit

 33 1 2/7 14x8 1 2 0.4
4148300398

CR-35-R25, R25

Cross Type Bit

 35 1 3/8 14x8 1 2 0.5
4148300399

CR-38-R25, R25

Cross Type Bit

 38 1 1/2 14x8 1 4 0.6
4148300400

CR-41-R25, R25

Cross Type Bit

 41 1 3/5 14x8 1 4 0.7
4148300401

CR-43-R25, R25

Cross Type Bit

 43 1 2/3 14x8 1 4 0.7
4148300402

CR-45-R25, R25

Cross Type Bit

 45 1 7/9 14x8 1 2 0.8
4148300403

CR-51-R25, R25

Cross Type Bit

 51 2     14x8 1 4 1.1





Applications

• Dimensional Stone Industry
• Underground Mining
• Tunneling

Packaging & Shipping

  Packaging:Carton or Wooden Box
