Home > Products > Taper Chisel Bit > Oblique Chipways Chisel Bit
Oblique Chipways Chisel Bit
- China Port
- L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Beijing, China | Brand Name | MIROC | |
| Model Number | 4148300087 | Material | Tungsten Carbide | |
| Use | Metal Drilling |
Product Description
Tungsten Carbide Tapered Chisel Drill Bit Hardened Steel Drill Bits
Product Specification
Tapered equipment affords drillers the ability to change drilling bits whilst still using the same drilling rod. Drillers choose tapered button bits for faster drilling penetration rate. Different taper sizes have different characteristics when it comes to the “knock-off” index – the smaller angle will prevent the bit from spinning.
• Suitable for small hole range
• Widely used in Dimensional Stone Quarrying Industry
• Widely used in Underground Mining Industry
Color: Green,Blue or Based on Customer requirements
Material: Tungsten carbide and high strength alloy steel
Processing: CNC milling and proprietary heat treatment process
Type: 7° Tapered Chisel Bit
Competitive Advantage
• High grade tungsten carbide inserts
• Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment
Why you choose tapered bit?
1.Tapered button bits connect with tapered drill rod perfectly for drilling holes
2.Stale and mature welding technology ensure high quality of bits
3.Accurate dimension of taper degree perfectly matches the rods
reliable and very cost-effective
5.High grade tungsten carbide inserts
6 Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment
Applications
• Suitable for small hole range
• Widely used in Dimensional Stone Quarrying Industry
• Widely used in Underground Mining Industry
Product Technical Reference
| Part Number | Product Code and Brief Description | Bit Diameter (mm) | Bit Diameter (inch) | Tip Size (W x H, mm) | Weight (kg) |
| 4148300075 | C26-7D-22, 7° Taper Chisel Bit | 26 | 1 | 10 x 7 | 0.17 |
| 4148300076 | C28-7D-22, 7° Taper Chisel Bit | 28 | 1 1/9 | 10 x 7 | 0.18 |
| 4148300077 | C30-7D-22-1, 7° Taper Chisel Bit | 30 | 1 1/6 | 13.5 x 8 | 0.22 |
| 4148300078 | C30-7D-22-2, 7° Taper Chisel Bit | 30 | 1 1/6 | 13.5 x 8 | 0.22 |
| 4148300079 | C32-7D-22-1, 7° Taper Chisel Bit | 32 | 1 1/4 | 13.5 x 8 | 0.24 |
| 4148300080 | C32-7D-22-2, 7° Taper Chisel Bit | 32 | 1 1/4 | 13.5 x 8 | 0.24 |
| 4148300081 | C34-7D-22-1, 7° Taper Chisel Bit | 34 | 1 1/3 | 13.5 x 8 | 0.27 |
| 4148300082 | C34-7D-22-2, 7° Taper Chisel Bit | 34 | 1 1/3 | 13.5 x 8 | 0.27 |
| 4148300083 | C36-7D-22-1, 7° Taper Chisel Bit | 36 | 1 3/7 | 13.5 x 8 | 0.3 |
| 4148300084 | C36-7D-22-2, 7° Taper Chisel Bit | 36 | 1 3/7 | 13.5 x 8 | 0.3 |
| 4148300085 | C38-7D-23-1, 7° Taper Chisel Bit | 38 | 1 1/2 | 13.5 x 8 | 0.33 |
| 4148300086 | C38-7D-23-2, 7° Taper Chisel Bit | 38 | 1 1/2 | 13.5 x 8 | 0.33 |
| 4148300087 | C38-7D-23-3, 7° Taper Chisel Bit | 38 | 1 1/2 | 15 x 9 | 0.33 |
| 4148300088 | C38-7D-23-4, 7° Taper Chisel Bit | 38 | 1 1/2 | 15 x 9 | 0.33 |
| 4148300089 | C40-7D-23-1, 7° Taper Chisel Bit | 40 | 1 4/7 | 13.5 x 9.2 | 0.38 |
| 4148300090 | C40-7D-23-2, 7° Taper Chisel Bit | 40 | 1 4/7 | 13.5 x 9.2 | 0.38 |
| 4148300091 | C40-7D-23-3, 7° Taper Chisel Bit | 40 | 1 4/7 | 13.5 x 9.2 | 0.38 |
| 4148300092 | C40-7D-23-4, 7° Taper Chisel Bit | 40 | 1 4/7 | 15 x 9.8 | 0.38 |
| 4148300093 | C40-7D-23-5, 7° Taper Chisel Bit | 40 | 1 4/7 | 15 x 9.8 | 0.38 |
| 4148300094 | C40-7D-23-6, 7° Taper Chisel Bit | 40 | 1 4/7 | 15 x 9.8 | 0.38 |
| 4148300095 | C40-7D-23-7, 7° Taper Chisel Bit | 40 | 1 4/7 | 15 x 9.8 | 0.38 |
| 4148300096 | C40-7D-23-8, 7° Taper Chisel Bit | 40 | 1 4/7 | 15 x 9.8 | 0.38 |
| 4148300097 | C42-7D-23-1, 7° Taper Chisel Bit | 42 | 1 2/3 | 13.5 x 9.2 | 0.41 |
| 4148300098 | C42-7D-23-2, 7° Taper Chisel Bit | 42 | 1 2/3 | 13.5 x 9.2 | 0.41 |
| 4148300099 | C42-7D-23-3, 7° Taper Chisel Bit | 42 | 1 2/3 | 13.5 x 9.2 | 0.41 |
| 4148300100 | C42-7D-23-4, 7° Taper Chisel Bit | 42 | 1 2/3 | 13.5 x 9.2 | 0.41 |
| 4148300101 | C42-7D-23-5, 7° Taper Chisel Bit | 42 | 1 2/3 | 15 x 9.8 | 0.41 |
| 4148300102 | C42-7D-23-6, 7° Taper Chisel Bit | 42 | 1 2/3 | 15 x 9.8 | 0.41 |
| 4148300103 | C42-7D-23-7, 7° Taper Chisel Bit | 42 | 1 2/3 | 15 x 9.8 | 0.41 |
| 4148300104 | C42-7D-23-8, 7° Taper Chisel Bit | 42 | 1 2/3 | 15 x 9.8 | 0.41 |
| 4148300105 | C43-7D-23-1, 7° Taper Chisel Bit | 43 | 1 2/3 | 13.5 x 9.2 | 0.42 |
| 4148300106 | C43-7D-23-2, 7° Taper Chisel Bit | 43 | 1 2/3 | 13.5 x 9.2 | 0.42 |
| 4148300107 | C43-7D-23-3, 7° Taper Chisel Bit | 43 | 1 2/3 | 15 x 9.8 | 0.42 |
| 4148300108 | C43-7D-23-4, 7° Taper Chisel Bit | 43 | 1 2/3 | 15 x 9.8 | 0.42 |
