Home > Products > Lifting Equipment > Technical parameters of Yutong 15T diesel internal combustion counterbalance forklift truck
Technical parameters of Yutong 15T diesel internal combustion counterbalance forklift truck
- 32 Set / Sets per Month
- TIANJIN/SHANGHAI/DALIAN/QINGDAO
- T/T L/C D/P D/A Credit Card
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | YUTONG |
Model Number: | YTCPD150-G1 | Type: | Powered Pallet Truck | Power Souce: | Diesel Engine |
Rated Loading Capacity: | 5000 | Max. Lifting Height: | 5000 | Min. Lifting Height: | 85 |
Fork Length: | 1370 | Fork Width: | 200 | Overall Dimensions: | 6105*2490*3220 |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Rated hoisting capacity | kg | 5000 | |
Maximum hoisting height | mm | 5000 | |
Full height when the fork falling to ground(portal frame appears to be vertical) | mm | 3220 | |
Load center distance | Mm | 600 | |
Minimum turning radius | Mm | 4800 | |
Minimum ground clearance (at the portal frame) | Mm | 260 | |
Fork dimension(Length* Width* Thickness) | Mm | 1370*200*85 | |
Overall dimension (with fork) | mm | 6105*2490*3220 | |
Axle distance | mm | 3100 | |
Front track | mm | 1804 | |
Rear track | mm | 2050 | |
Adjusting clearance between two forks | mm | 490-2400 | |
Tilting angle of portal frame(Front/Rear) | . | 6/6 | |
Tyre | Front tyre | - | 12.00-20-14PR |
Rear tyre | - | 12.00-20-14PR | |
Engine | Model |
| Cummins QSB6.7 |
Rated power | kW/rpm | 119/2200 | |
Maximum torque | N.m/rpm | 732/1500 | |
Displacement | L | 6.7 |
Introduction of product selling points:
The complete vehicle adopts streamlined appearance, it has a strong power and small turning radius, being flexible and highly stable in motion.
Power system:
It adopts the original 6BG1 diesel engine produced by ISUZU company in Japan, with strong horsepower and compliant to the National II emission standards.
The five main performance of this type of vehicle are significantly improved, and its quality become more superior.
1.Reliable power system
The system is equipped with a transmission specially designed and produced for this vehicle model(The transmission body is made of lost foam casting, and equipped with air filter pressure warning device,cyclone air filter, automatic preheating system of engine,its mean time between failures can reach 8000 hours). Having weathered the test of markets for over 20 years, this product is the most reliable transmission system. Therefore, the fault rate of complete vehicle will be greatly reduced.Moreover, several auxiliary power unit ensures the reliable operation of this system effectively.
2.Reliable hoisting system
The solid portal frame that emphasis the interior quality( larger cross-section of portal frame steel channel and a more tighten structure) provides a credible safety assurance for operators. The standard configuration of high visibility portal frame avails a clearer vision.
3.Reliable hydraulic system
Yutong grasps the the most professional oil cylinder development and production base, in which the world leading manufacturing technology and inspection methods are implemented to ensure the reliability of each oil cylinder in hydraulic system(self-lock function of tilt cylinder,standard hydraulic loop filter,falling speed limiting function of oil channel).
4. Reliable steering system
The standard configuration of electro-hydraulic directional system makes the operation convenient and labor saving, and the steering system that adopts new technology not only provides smoother and faster positioning as well as steering, but also ensures the safety of driver.
5. Comfortable operation space
Larger operation space,accompany with the design and configuration of multiple human engineering is more convenient and comfortable for operation, which effectively enhance the working performance and safety.
