YTZ5200JSQ20E 8-tonTruck-Mounted Crane
The truck with loading crane whose key components are imported original products is a newly developed yutong special purpose vehicle with such advantages as high reliability, strong hoisting and loading ability, reasonable design and easy operation. It can be widely used in the traffic and transport, civil engineering, electric power, petroleum, stone industry and dock for loading and unloading of goods, resye and long-distance freight transfer.
Technical Parameter
Declared external dimension (mm) |
11000×2500×3800 |
Actual external dimension (mm) |
11000×2500×3800 |
Chassis model |
DFL1200AX9 |
Dimension of car body |
7400×2300×550 |
Total Weight(kg) |
15206 |
Rated load (Kg) |
6730 |
Maximum vehicle speed (km/h) |
90 |
Wheelbase (mm) |
5350+1300 |
Front suspension/rear suspension (mm) |
14602890 |
Approach angle/departure angle(°) |
20/12 |
Wheel track of front wheel (mm) |
1986 |
Wheel track of rear wheel (mm) |
1860 |
Crane Model |
SQ8SA3 |
Max. rating load(kg) |
8000 |
Max. working range (m) |
11.2 |
Max. lifting height(m) |
14.5 |
characteristics of 8-tonTruck-Mounted Crane
1. Booms adopt synchronous retraction mode which features high speed, high efficiency and increases hoisting capacity and extends crane's service life.
2. Large displacement oil pump is used. When the engine is running at idle, the operating device can run quickly, therefore saving energy and fuel, and creating greater value for the customer.
3. Hydraulic system can be interlocked when the operator gets on and off the crane, in order to avoid misoperation and ensure safe and reliable operation.
4. Optimized high-level sub-frame structure improves the strength of the frame.
5. Through cooperation with chassis manufacturers such as Dongfeng, the chassis performance parameters are matched with the crane performance parameters more reasonably, greatly increasing the overall operation performance of the crane.
As a specialized supplier of construction machinery of PLA Construction Engineering Corps, Yutong Heavy Industries has made outstanding contributions to the national defense construction, supplied thousands of various equipment like high-speed bulldozers and loaders for this Corps, and been highly appraised by the army due to the high quality of its products in the past 60 years.
Welcome to consult us any question you have !
