Home > Products > Lifting Equipment > China 3 Ton Electric Drive Fork Lift Truck
China 3 Ton Electric Drive Fork Lift Truck
- 240 Piece / Pieces per Month
- Qingdao Port Tianjin port Lianyungang port Shanghai port
- T/T L/C Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | YUTONG |
Model Number: | YTD3T | Type: | Powered Pallet Truck | Power Souce: | Diesel Engine |
Rated Loading Capacity: | 3000kg | Max. Lifting Height: | 3000mm | Min. Lifting Height: | 135mm |
Fork Length: | 1070mm | Fork Width: | 122 Mm | Overall Dimensions: | 3818*1225*2170mm |
Certification: | CE/ISO9001 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
China 3 Ton Electric Drive Fork Lift Truck
Rated hoisting capacity | kg | 3000 | |
Maximum hoisting height (m) | mm | 3000 | |
Full height when the fork falling to ground(portal frame appears to be vertical) | mm | 2065 | |
Load center distance | Mm | 500 | |
Free hoisting height | Mm | 160 | |
Minimum turning radius | Mm | 2400 | |
Minimum ground clearance (at the portal frame) | Mm | 135 | |
Fork dimension(Length* Width* Thickness) | Mm | 1070*122*45 | |
Overall dimension(with fork) | mm | 3818*1225*2170 | |
Front suspension | mm | 478 | |
Wheelbase | mm | 1700 | |
Front track | mm | 1000 | |
Rear track | mm | 970 | |
Adjusting clearance between two forks | mm | 250-1060 | |
Tilting angle of portal frame(Front/Rear) | . | 6/12 | |
Maximum traction (full load) | KN | 19 | |
Tire | Front tire | - | 28.9-15-12PR |
Rear tire | - | 6.50-10-10PR | |
Engine | Model |
| ISUZU C240PKJ |
Rated power | kW/rpm | 35.4/2500 | |
Maximum torque | N.m/rpm | 139.9/1800 | |
Displacement | L | 2.369 | |
Battery voltage/volume | V/AH | 12/80 | |
Mass of forklift truck | Kg | 4370 |
1.The complete vehicle adopts streamlined appearance, it has a strong power and small turning radius, being flexible and highly stable in motion. 2.Power system adopts the original C240 diesel engine produced by ISUZU company in Japan, with strong horsepower and compliant to the Euro III emission standards.. 3.Connecting by shock mount, the whole-suspension cab can effectively absorb the vibration of vehicle body. | |
4.The shock absorber is equipped under the hoisting device so as to reduce the shock and vibration of portal frame, and avoid the noise generated when the cargo falling to the ground. 5.The steering gear is moved upwardly, while the inching brake adopts a suspension type, which greatly increased the space under feet. 6.The electrical system adopts electro-hydraulic proportional control technology and CAN bus distributed control technology. 7.Inner space of the vehicle expands, which is convenient for engine and gear box maintenance. 8.Increases in opening angle of hood can help you achieve a convenient and fast maintenance. |
"12380"Service after sale. We can offer: 1.After receiving the customer mobile, we will help customer solve problem through removing the resources of Yutong service and reply the customer clearly in one hours; 2: To improve the service quality all the time, in 2working days of the end of on-sit service, we will pay a return visit about the satisfaction of after sale service; 3: To comprehensive systematically and professionally maintenance and repair for the customer product, we will have 3 times On-Site Inspection forwardly in warranty period; 8:The service engineer will solve problem in 8 hours after getting to on-sit. If the problem is not solve ,the service engineer can not leave the on-sit; 0: To eliminate customer worries, from receiving order to product scrapping, Yutong will provide full reliance, seamless docking and service in the period of product using. |
Yutong Heavy Industry is China's top 500 enterprises Yutong Group's core subsidiary, is a leading supplier of specialized mining, infrastructure and sanitation machinery and equipment package of solutions. The company is the cradle of Chinese construction machinery design and manufacturing, since 1958, China's first hydraulic torque converter, the first power shift transmission, the first self-propelled scrapers, the first large horsepower tire type tractors, more than 30 "China's first" all born here! factory occupies 2102 acres, with more than 3,000 people, including more than 470 man-made construction machinery senior technical staff, and has academician workstation and provincial enterprise technology center. Yutong Heavy Industries as a quality supplier of PLA, every year a large loaders and bulldozers to the military. We also provide the United Nations had as loaders, bulldozers and wreckers, and obtained the creation of the United Nations awarded the Star of Science Award. Our company is China's first loader KD line exporter, currently this KD line services in Iran, the annual amount of 300 assembly, and its products can cover the Middle East, many countries such as: Saudi Arabia, Turkey and Azerbaijan. Also Our rotary drilling rig, successfully sold to the United States five devices, and job conditions in Alaska minus 50 degrees. Our product is in Africa an affirmative president of Nigeria, the African business people and our next president our photo equipment. Our sanitation garbage package of solutions and services in Ghana is the country for the African brothers to improve their living environment contribute our part. In South America, Cuba and Venezuela, we are the government's long-term strategy for its suppliers. Rotary Drilling Division I Participation in 2008 Olympic Games in the Bird's Nest construction work, and successfully laid the first pile. |
We are military equipment supplier, our original facotry is founded at 1958. Good quality and competitive price is our advantage.
For quality guarate, we give one year guarantee, and with 24hours response principle for better service. We have more than 30 agency all over the world, you can get the most convenient service by nearest agency.
We accept T/T, L/C, D/P, D/A,even L/G. |
