China Long Arm Small Garden Tractor With Front-End Loader
Main Technical Parameters
Overall dimension (length x width x height) (mm) |
7030×2510×3185 |
|
Rated load (kg) |
3000 |
|
Rated capacity of bucket (m3) |
1.76 |
|
Weight of complete machine (kg) |
10330 |
|
Maximum unloading height (mm) |
3215 |
|
Unloading distance (mm) |
1090 |
|
Sum time of three items (s) |
9.6 |
|
Wheelbase (mm) |
2607 |
|
Wheel track (mm) |
1800 |
|
Breakout force (kN) |
103 |
|
Maximum traction (kN) |
100 |
|
Maximum traveling speed (km/h) |
35 |
|
Minimum turning radius |
4929 |
|
Maximum gradeability (°) |
25° |
|
Engine model |
YC6J125Z-T21 |
|
Rated power of engine (kw/hp) |
92 /125 |
|
Rated speed of engine (rpm) |
2300 |
|
Maximum torque of engine (N.m) |
480 |
|
Engine displacement |
Euro II |
|
Braking way |
Caliper disc brake |
|
Tire model |
17.5-25 12PR |
|
Pressure of working system (MPa) |
17 |
|
Operation manner of working system |
Connecting rod operation |
|
A/C system |
Warm air blower |
|
1.This wheel loader is equipped with Yuchai turbocharged engine (Euro II), has large power and low fuel consumption and can save energy and protect environment. 2.Wheel loader is equipped with a torque converter which has reliable quality and superior performance in the industry, BS428 gearbox produced by Hangzhou Advance Gearbox, as well as heavy loading drive axle, resulting in large tractive force. 3.The optimized torque converter of wheel loader largely improves the tractive force. The unloading speed is quick and the breakout force is large. The vehicle has high efficiency and can save energy and protect environment. |
|
4.The wheel loader is flexible, with flexible steering, short wheelbase and small turning radius. 5.Due to wear-resistant blades and bucket teeth, the service life of bucket becomes longer. 6."C"-shaped protecting bush of wheel loader is used at the hinge joint of hinge pin, which has good dustproof effect and makes the hinge joint of hinge pin more wearable. 7.The working system of wheel loader adopts rear-mounted multi-way valve and is operated by connecting rod. The operation is easy and flexible, with good hand feeling and high reliability. 8.According to CAE analysis, the front and rear vehicle frames of wheel loader are optimized, impact resistance is improved and the fatigue life becomes longer. 9.The casting-type beam of movable arm of the whole machine, optimized by the postdoctoral workstation of our company, has more reasonable structural design. |
|
|
"12380"Service after sale. We can offer: 1.After receiving the customer mobile, we will help customer solve problem through removing the resources of Yutong service and reply the customer clearly in one hours; 2: To improve the service quality all the time, in 2working days of the end of on-sit service, we will pay a return visit about the satisfaction of after sale service; 3: To comprehensive systematically and professionally maintenance and repair for the customer product, we will have 3 times On-Site Inspection forwardly in warranty period; 8:The service engineer will solve problem in 8 hours after getting to on-sit. If the problem is not solve ,the service engineer can not leave the on-sit; 0: To eliminate customer worries, from receiving order to product scrapping, Yutong will provide full reliance, seamless docking and service in the period of product using. |
|
|
|
|
|
Yutong Heavy Industry is China's top 500 enterprises Yutong Group's core subsidiary, is a leading supplier of specialized mining, infrastructure and sanitation machinery and equipment package of solutions. The company is the cradle of Chinese construction machinery design and manufacturing, since 1958, China's first hydraulic torque converter, the first power shift transmission, the first self-propelled scrapers, the first large horsepower tire type tractors, more than 30 "China's first" all born here! factory occupies 2102 acres, with more than 3,000 people, including more than 470 man-made construction machinery senior technical staff, and has academician workstation and provincial enterprise technology center. Yutong Heavy Industries as a quality supplier of PLA, every year a large loaders and bulldozers to the military. We also provide the United Nations had as loaders, bulldozers and wreckers, and obtained the creation of the United Nations awarded the Star of Science Award. Our company is China's first loader KD line exporter, currently this KD line services in Iran, the annual amount of 300 assembly, and its products can cover the Middle East, many countries such as: Saudi Arabia, Turkey and Azerbaijan. Also Our rotary drilling rig, successfully sold to the United States five devices, and job conditions in Alaska minus 50 degrees. Our product is in Africa an affirmative president of Nigeria, the African business people and our next president our photo equipment. Our sanitation garbage package of solutions and services in Ghana is the country for the African brothers to improve their living environment contribute our part. In South America, Cuba and Venezuela, we are the government's long-term strategy for its suppliers. Rotary Drilling Division I Participation in 2008 Olympic Games in the Bird's Nest construction work, and successfully laid the first pile. |
We are military equipment supplier, our original facotry is founded at 1958. Good quality and competitive price is our advantage.
For quality guarate, we give one year guarantee, and with 24hours response principle for better service. We have more than 30 agency all over the world, you can get the most convenient service by nearest agency.
We accept T/T, L/C, D/P, D/A,even L/G. |
|
