China Long Arm 3 Ton Front-end Loader
Main Technical Parameters of Wheel Loader
Overall dimension (length x width x height) (mm) |
7050×2510×3200 |
|
Rated load of wheel loader (kg) |
3000 |
|
Rated capacity of bucket (m3) |
1.70 |
|
Weight of complete machine (t) |
10.2-10.5 |
|
Maximum unloading height (mm) |
3215 |
|
Unloading distance (mm) |
1090 |
|
Sum time of three items (s) |
≤9.6 |
|
Wheelbase (mm) |
2607 |
|
Wheel track (mm) |
1800 |
|
Breakout force (kN) |
103 |
|
Maximum traction (kN) |
100 |
|
Maximum traveling speed (km/h) |
35 |
|
Minimum turning radius |
4929 |
|
Maximum gradeability (°) |
25° |
|
Engine model |
YC6J125Z-T21/Cummins |
|
Rated power of engine (kw/hp) |
92 /125,97/13 |
|
Rated speed of engine (rpm) |
2300 |
|
Maximum torque of engine (N.m) |
480 |
|
Engine displacement |
Euro2/3 |
|
Braking way |
Caliper disc brake |
|
Tire model |
17.5-25 12PR |
|
Pressure of working system (MPa) |
17 |
|
Operation manner of working system |
Flexible axle operation |
|
A/C system |
Warm air blower |
Serial number |
Project |
Parameter |
|
1 |
Engine |
Dongfeng cummins engine meeting national standard II |
|
Dongfeng cummins engine meeting national standard III |
|
||
2 |
Shovel bucket |
Common bucket (bolted bucket teeth) |
1.76 m³ |
Rock bucket |
1.76m³ |
||
Coal bucket |
2.2 m³ |
||
Meterloose material bucket |
3 m³ |
||
3 |
Else |
Common arm |
|
Single rod pilot |
|
||
Kunlun tyre |
|
||
Grass grasping changing device |
|
||
Pipe grasping changing device |
|
||
Bottom fork changing device |
|
||
Quick changing bucket |
|
||
Quick changing bottom fork |
|
||
Quick changingwood clamping component |
|
||
Quick changinggrass grasping component device |
|
||
Reload screening bucket |
|
||
Added concentrate lubrication system |
|
||
Add bucket automatic flat and swing arm lifting limit device |
|
||
Added spinning alarm lamp |
|
||
Antiskid chain(1 set) |
|
||
Added reverse video system |
|
||
Added air-conditioning system |
|
||
Reload anti-tilt cab |
|
||
Yutong yellow paint |
|
||
Carter yellow paint |
|
||
Varnish |
|
||
|
1.This loader is equipped with Yuchai turbocharged engine (Euro2 or Euro3), which has strong horsepower and large torque reserves and can save energy and protect environment. 2.YJ315 torque converter of loader (single-stage, single-phase and 3-element) has large torque coefficient (3.23) and high efficiency. 3.The heavy loading drive axle of wheel loader has large load capacity and high reliability. |
|
4.The torque converter of wheel loader is optimized and the lifting and loading speeds are largely promoted. The sum time of three items becomes shorter. 5.The wheel loader is flexible, with flexible steering, short wheelbase and small turning radius. 6.According to CAE analysis, the front and rear vehicle frames of loader are optimized, impact resistance is improved and the fatigue life becomes longer 7.The casting-type beam of movable arm of the whole machine, optimized by the postdoctoral workstation of our company, has more reasonable structural design. 8.The modeling of this loader has received national design patent (Patent No. ZL200630301778.2) and is loved by the majority of users. 9. loader is equipped with a cab with luxurious interior and control components that are designed according to ergonomic principles, providing easy and comfortable operation for the driver. |
|
|
"12380"Service after sale. We can offer: 1.After receiving the customer mobile, we will help customer solve problem through removing the resources of Yutong service and reply the customer clearly in one hours; 2: To improve the service quality all the time, in 2working days of the end of on-sit service, we will pay a return visit about the satisfaction of after sale service; 3: To comprehensive systematically and professionally maintenance and repair for the customer product, we will have 3 times On-Site Inspection forwardly in warranty period; 8:The service engineer will solve problem in 8 hours after getting to on-sit. If the problem is not solve ,the service engineer can not leave the on-sit; 0: To eliminate customer worries, from receiving order to product scrapping, Yutong will provide full reliance, seamless docking and service in the period of product using. |
|
|
|
|
|
Yutong Heavy Industry is China's top 500 enterprises Yutong Group's core subsidiary, is a leading supplier of specialized mining, infrastructure and sanitation machinery and equipment package of solutions. The company is the cradle of Chinese construction machinery design and manufacturing, since 1958, China's first hydraulic torque converter, the first power shift transmission, the first self-propelled scrapers, the first large horsepower tire type tractors, more than 30 "China's first" all born here! factory occupies 2102 acres, with more than 3,000 people, including more than 470 man-made construction machinery senior technical staff, and has academician workstation and provincial enterprise technology center. Yutong Heavy Industries as a quality supplier of PLA, every year a large loaders and bulldozers to the military. We also provide the United Nations had as loaders, bulldozers and wreckers, and obtained the creation of the United Nations awarded the Star of Science Award. Our company is China's first loader KD line exporter, currently this KD line services in Iran, the annual amount of 300 assembly, and its products can cover the Middle East, many countries such as: Saudi Arabia, Turkey and Azerbaijan. Also Our rotary drilling rig, successfully sold to the United States five devices, and job conditions in Alaska minus 50 degrees. Our product is in Africa an affirmative president of Nigeria, the African business people and our next president our photo equipment. Our sanitation garbage package of solutions and services in Ghana is the country for the African brothers to improve their living environment contribute our part. In South America, Cuba and Venezuela, we are the government's long-term strategy for its suppliers. Rotary Drilling Division I Participation in 2008 Olympic Games in the Bird's Nest construction work, and successfully laid the first pile. |
We are military equipment supplier, our original facotry is founded at 1958. Good quality and competitive price is our advantage.
For quality guarate, we give one year guarantee, and with 24hours response principle for better service. We have more than 30 agency all over the world, you can get the most convenient service by nearest agency.
We accept T/T, L/C, D/P, D/A,even L/G. |
|
