Specifications
High strength steel with high fatigue strength and excellent wear resistance
In DTH drilling, the rock drilling bit is a continuation of the shank, which the rock drill piston strikes directly. Since the piston is in direct contact with the drill bit, little energy is lost. This gives DTH drilling a nearly constant penetration rate regardless of hole length.
DTH drilling enables drillers to reach hole depths that are double of what top hammer drilling can do. This is possible with the use of DTH Pipes and DTH Subs.
• High grade steel used on thread area and main drill pipe body
• Automated welding process used in joining the thread area and main drill pipe body
Product Name: |
DTH drill pipe |
|||||
Description: |
dth button bit are used for blast hole drilling and water well drilling project. Working with DTH drilling pipe and DTH drill bit, mainly applied in Mining, Marble quarry or well drilling and other construction projects. |
|||||
Quality level: |
95% similarity to COP/SD/MISSION/QL/BR/DHD etc famous brand |
|||||
MOQ: |
No requirement for testing and trial order |
|||||
Series: |
COP/ SD/ DHD/ IR/ Mission/ QL/ BR/ CIR etc |
|||||
Applications
• Underground mining
• Quarry benching operations
• Water well drilling
Competitive Advantage
High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance
Specification of DTH Drill pipe
Part Number |
Product Code and Brief Description |
Outer Diameter (mm) |
Outer Diameter (inch) |
Thread |
Drill Pipe Thickness (mm) |
4148301544 |
DTHP76-1000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
5.5 |
4148301545 |
DTHP76-1500, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
5.5 |
4148301546 |
DTHP76-2000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
5.5 |
4148301547 |
DTHP76-3000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
5.5 |
4148301548 |
DTHP76-1000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
5.5 |
4148301549 |
DTHP76-1500, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
5.5 |
4148301550 |
DTHP76-2000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
5.5 |
4148301551 |
DTHP76-3000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
5.5 |
4148301552 |
DTHP76-3000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
6.5 |
4148301553 |
DTHP76-4500, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
6.5 |
4148301554 |
DTHP76-6000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
6.5 |
4148301555 |
DTHP89-1000, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
5.5 |
4148301556 |
DTHP89-1500, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
5.5 |
4148301557 |
DTHP89-2000, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
5.5 |
4148301558 |
DTHP89-3000, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
5.5 |
4148301559 |
DTHP89-1000, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
6.5 |
4148301560 |
DTHP89-1500, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
6.5 |
4148301561 |
DTHP89-2000, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
6.5 |
4148301562 |
DTHP89-3000, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
6.5 |
4148301563 |
DTHP89-4500, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
6.5 |
4148301564 |
DTHP89-6000, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
6.5 |
