Home > Computer Products > Network Hardware & Parts > Other Network Hardware & Parts > Ruckus ZoneFlex R700 Dual-band 802.11abgn/ac Wireless Access Point

Ruckus ZoneFlex R700 Dual-band 802.11abgn/ac Wireless Access Point

Ruckus ZoneFlex R700 Dual-band 802.11abgn/ac Wireless Access Point thumbnail-1
Ruckus ZoneFlex R700 Dual-band 802.11abgn/ac Wireless Access Point thumbnail-2
Ruckus ZoneFlex R700 Dual-band 802.11abgn/ac Wireless Access Point photo-1
Ruckus ZoneFlex R700 Dual-band 802.11abgn/ac Wireless Access Point photo-2
Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Brand Name:
Ruckus
Model Number:
Zoneflex R700
Contact Supplier Request Quote Chat Now
Shenzhen Importgm Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Brand Name Ruckus
Model Number Zoneflex R700
Place of Origin Oregon, United States
ZoneFlex R700 Specifications
Physical Characteristics
Power
  • DC Input: 12 VDC 1.5A
  • PoE: 802.3af compliant
Physical Size
  • 20.3 cm (L), 20.3 cm (W), 5 cm (H)
  • (7.99 in, 7.99 in, 1.99 in)
Weight 1kg (2.25 lbs.)
RF (1,2,3)
  • Adaptive antenna array that provides 3,000+ unique antenna patterns
  • Maximum Transmit Power(1) 24 dBm on 2.4 GHz; 22 dBM on 5 GHz
  • Physical antenna gain: 3 dBi (2.4 and 5GHz)
  • BeamFlex SINR Tx gain(2): up to 6 dB
  • BeamFlex SINR Rx gain: up to 4 dB
  • Interference mitigation: up to 15 dB
  • Minimum Rx sensitivity(3): -99 dBm
Ethernet Ports
  • 2 ports, auto MDX, auto-sensing 10/100/1000 Mbps, RJ-45
  • Power over Ethernet (802.3af) with Category 5/5e/6 cable
Environmental Conditions
  • Operating Temperature: 32°F (0°C) - 122°F (50°C)
  • Operating Humidity: up to 95% non-condensing
Power Consumption
  • 5W (minimum)
  • 7W (typical)
  • 13W (peak)
Performance and Capacity
PHY Data Rates
  • Up to 450 Mbps (2.4GHz)
  • Up to 1300Mbps (5GHz)
Concurrent Stations Up to 500
Simultaneous VoIP Clients Up to 60 (802.11e/WMM support), 30 per radio
Network Architecture
IP IPv4, IPv6, dual-stack
VLANs
  • 802.1Q (1 per BSSID or dynamic, per user based on RADIUS)
  • Port-based
802.1x for Wired Ports
  • Authenticator
  • Supplicant
Tunneling L2TP, PPPoE
Multimedia and Quality of Service
802.11e/WMM Supported
Software Queues Per WLAN priority (2), Per traffic type (4), per client
Traffic Classification Automatic, heuristics and TOS based or VLAN-defined
Rate Limiting Dynamic per-user or per-WLAN
Management
Deployment Options
  • Standalone (individually managed)
  • Managed by ZoneDirector
  • Managed by FlexMaster
Configuration
  • Web User Interface (HTTP/S)
  • CLI (Telnet/SSH), SNMP v1, 2, 3
  • TR-069 vis FlexMaster
Auto Software Updates FTP or TFTP, remote auto available
Wi-Fi
Standards
  • IEEE 802.11a/b/g/n/ac
  • 2.4GHz and 5GHz concurrent operation
Supported Data Rates
  • 802.11ac: 29.3 Mbps – 1300 Mbps (80MHz)
  • 802.11n: 6.5 Mbps – 216.7 Mbps(20MHz) 13.5 Mbps – 450 Mbps (40MHz)
  • 802.11a: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
  • 802.11b: 11, 5.5, 2 and 1 Mbps
  • 802.11g: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
Radio Chains / Streams 3 x 3:3
Channelization 20 MHz, 40 MHz, and/or 80 MHz
Frequency Band
  • IEEE 802.11ac: 5.15 – 5.85 GHz
  • IEEE 802.11a/n: 5.15 – 5.85 GHz
  • IEEE 802.11b: 2.4 – 2.484 GHz
Operating Channels
  • US/Canada: 1-11, Europe ( ETSI X30): 1-13, Japan X41: 1-13
  • 5 GHz channels: Country dependent
BSSIDs
  • Up to 32 (2.4 GHz)
  • Up to 8 (5 GHz)
Power Save Supported
Certifications*
  • WEEE/RoHS compliance
  • EN 60601-1-2 (Medical)
  • Wi-Fi Alliance certified (Pending)
  • UL 2043 plenum rated
Subway and Railroad Certifications
  • EN50121-1 EMC
  • EN50121-4 Immunity
  • IEC 61373 Shock & Vibration
