ZoneFlex T300 Unleashed omni, Outdoor access point with 1 Year Support Bundle
802.11ac 2x2:2 internal BeamFlex+, dual band concurrent, one ethernet port, PoE input, includes mounting bracket and one year warranty. Does not include PoE injector
Includes 1 Year Support from Ruckus Wireless
Overview
The ZoneFlex T300 Series Unleashed enable controller-less Wi-Fi architecture for small business environments with superior performance, lower costs and simplified management. Separate controllers and access point licenses are no longer needed, significantly reducing upfront costs. Set up is also easy, thanks to a simplified web interface that helps businesses configure Wi-Fi in just 60 seconds.
The ZoneFlex T300 Series are the first dual-band 802.11ac outdoor access points (APs) designed explicitly for high density public venues such as airports, conventions centers, plazas & malls, and other dense urban environments.
These environments require support for users that demand high capacity and mobile device ready WLAN services. The T300 is uniquely designed to serve these demanding environments with dual-polarized adaptive antennas that dynamically select the best antenna patterns on a per packet basis to provide reliable client connections and to increase network capacity while implicitly mitigating interference and improving signal-to-interference -plus-noise ratio (SINR).
More Details
| Physical Characteristics | |
|---|---|
| Power | 802.3af PoE Input (Class 3 PD) |
| Physical Size | 7” x 5.9” x 3.4” (18cm x 15cm x 8.6cm) |
| Weight | 2.1 lbs (1 kg) with bracket 2 lbs (0.9 kg) without bracket |
| Ethernet Ports | 10/100/1000Base-T 802.3,802.3 u,802.3ab 802.3at/af PoE PD Input Jumbo frame support (2290 byte max MTU) |
| RF Connectors | N female qty 2 (optional 5GHz only) |
| Environmental Conditions | Operating temperature range: -20°C to 55° C Weather protection: IP67 per IEC 60529 |
| Power Draw | PoE Input Idle: 6.5W Typical: 7.5W Peak: 11W |
| Mounting Options | Wall Mount Pole Mount Diameter 1” to 2.5” |
| Performance and Capacity | |
| Physical Layer Modulation Data Rate | 2.4GHz 802.11b/g/n 300Mbps 5GHz 802.11a/n/ac 867Mbps |
| Concurrent Stations | Up to 512 clients per AP |
| Simultaneous VoIP Clients | Up to 30 |
| Wi-Fi | |
| Standards | 5 GHz IEEE 802.11ac 2GHz IEEE 802.11g/n |
| Frequency Bands | IEEE 802.11g/n 2.4-2.472GHz (ch1-13 CE, ch1-11 US) IEEE 802.11ac 5GHz U-NII-1 5.15-5.25 GHz U-NII-2 5.25-5.35 (DFS) U-NII-2B 5.37-5.47 U-NII-2C 5.47-5.725 (DFS) U-NII-3 5.725-5.825 ISM 5.725 – 5.875 U-NII-4 5.85-5.925 |
| WLAN Radio Configuration | Dual band concurrent 2 x 2:2 stream radios |
| Maximum TX Power | 26 dBm for 2.4GHz 25 dBm for 5.0GHz |
| Channelization | 2.4GHz 802.11b/g/n 20/40 MHz 5GHz 802.11a/n/ac 20/40/80 MHz |
| BSSID | Up to 32 (27 configurable) on 2.4 GHz Up to 16 (13 configurable) on 5 GHz |
| Certifications | U.S., Europe, Argentina, Australia, Brazil, Canada, Chile, China, Colombia, Costa Rica, Hong Kong, India, Indonesia, Israel, Japan, Korea, Malaysia, Mexico, Peru, Philippines, Russia, Saudi Arabia, Singapore, South Africa, Taiwan |
