Home > Security & Protection > Access Control System > Access Controller > Bio460 Advanced Biometric Access Control Panel

Bio460 Advanced Biometric Access Control Panel

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

OEM

Model Number:

Bio460

Contact Supplier Request Quote Chat Now

Shenzhen Importgm Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name OEM

Model Number Bio460

Introduction:

BIO460 is the most advanced access control panel which can provide biometric security for any door when connected with biometric readers and the software.These panels are versatile and can connect both F series of fingerprint readers and KR series of RFID readers. These readers can be connected with TCP/IP and RS 485 connectivity to the panels. With the help of Access software the user will get the flexibility and scalability to program the access control system. The software is web based and hence can be accessed from any computer with the help of a web browser.

Parameter index:

Truly Internal Biometric Identification

BIO460 panel carries out the matching of fingerprints on the panels. The fingerprint templates from the reader are transmitted to the panel and the panel will match the placed finger with the template stored in the database. With the powerful version 10 algorithm, the fingerprint matching is extremely fast and accurate

Dual Communication Mode

inBIO460 supports dual communication modes, i.e. TCP/IP mode and RS485 mode. TCP/IP communication offers unparallel speed and reliability but is limited to 300ft of cable length between the panel and the reader. With RS 485 you can extend the cable length between the reader and panel up to 1km

LED Indicators

Five LED indicators inside the housing of inBIO460 panel are used to indicate power, steady functioning of the panel, valid identification and data transfer from inBIO460 to readers

External SD card support

inBIO460 can store 100,000 transactions in its internal memory. However for special projects or applications which require more storage capacity, a SD card can be added to inBIO260 for storage of data. It also helps in backing up the data from the controller.

Surveillance Linkage

Users could connect inBIO460 with DVR, and have video surveillance linkage function in Access5.0 Software. When the linkage is established, users can monitor live video

Salient Access Control Functions

Interlock, Anti-Pass Back, First Card Opening, Multi-Card Opening, Duress Password and Fingerprint, Remote Monitoring, Real-Time Monitoring and E-map Linkage. All of these functions are compatible with the third party accessories like exit switches, PIR detectors, card readers, alarms and RTE hardware

Model	BIO460
CPU	32bit MIPS CPU
RAM	32M bits
Flash Memory	128M bits
Fingerprint Capacity	3000
Card Capacity	30,000
Event Buffer	100,000
SD Card Backup	Support
Power / Current	DC 9.6V-14.4V, Rated Max.1A
Wiegand Reader Port	4ea (26bit Wiegand, 8bit Burst for PIN)
RS485 Reader Port	1ea Extended RS485 Port
Communication	RS485, TCP/IP
Baud Rate	38,400bps (Recommended) / 9600bps, 19,200bps, 57,600bps (selectable)
Input Port	8ea (Exit Button#1, Door Sensor#1; Exit Button#2, Door Sensor#2; Exit Button#3, Door Sensor#3; Exit Button#4, Door Sensor#4)
Output Port	4ea (4 FORM-C Relay Output, SPDT 5A@36VDC/8A@30VAC)
Output Port	4ea ( 4 Aux FORM-C Relay Output, SPDT 2A@30VDC)
LED Indicator	Yes, LED indication for communication, power, status and punch card
Operating Temperature	0°to +55°C
Operating Humidity	10% to 80% relative humidity non-condensing
*Dimension (HWD)mm*	18510636(single board) 40033090.5(with power supply and metal cabinet)
Housing Material	PVC
