Networked and Standalone RFID Card Reader (RF100)

Networked and Standalone RFID Card Reader (RF100) thumbnail-1
Networked and Standalone RFID Card Reader (RF100) photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Techcrepower
Model Number:
RF100 RFID Card Reader
Contact Supplier Request Quote Chat Now
Shenzhen Importgm Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Techcrepower
Model Number RF100 RFID Card Reader

Networked and Standalone RFID Card Reader (RF100)



Product Introduction:



RF100 is an access control devices without LCD and Kaypad which enhance the functions of waterproof and dustproof. It is made with elegant design and professional surface treatment. The devices have lock control, alarm, exit button, door sensor. The wiegand in interface is used to connect external reader to construct master and slave system. Also the device can connect to Access Control Panel as a reader by wiegand-out interface. SCR100 is suitable for house, small office and factory etc.


Features:



· Elegant design with Acrylic plastic
· Revolutionary products in industry with TCP/IP interface, avoid RS485 communication and low speed for transferring data,  standalone or network deployment
· Protect the data with encrypted technology
· Professional access control function: 50 time zones, 5 groups, 10 open door combination, support multi users entry
· Built-in relay contacts lock, alarm, door sensor & exit button
· Wiegand input&output enable Master/Slaver access control
· Embedded webserver: support browser to inquire access data at local or remote
· No LCD and no keypad enhance the functions of waterproof and dustproof



Technical Specification:



Card Holders 30,000 cards
Transaction Capacity  50,000 events
Read Range 5-10 cm
Reading Time (Card) <30mS
Platform ZEM500 (Embedded Linux O/S)
Communication  RS232/484,TCP/IP
Built-in Relay  Built-in Relay for Door Sensor, alarm, EM-Strike/Magnetic lock, exit button
Wiegand  Wiegand 26 Input/Output
LED Indicator 3 Color LED Indicators(Blue ,Red and Green) with audible beep; Blue: Normal standby mode;  Red: Access denied;Green: Access granted
Optional functions MF card, iClass card, Web server, Anti-pass back
Power Supply 12V DC 3A
Operating Temperature 0°C-45°C
Operating Humidity 20%-80%
Dimension 153x95.5x35.5mm
Net Weight 0.8kg


Product Photo

Networked and Standalone RFID Card Reader (RF100)



Networked and Standalone RFID Card Reader (RF100)



Networked and Standalone RFID Card Reader (RF100)



Networked and Standalone RFID Card Reader (RF100)





Product Certification



Our Factory



Our Advantage

1. Original High Quality Products:

All of our products are Original High Quality Products, We have strict quality control system, they are 100% tested before factory,

we don’t sell products with only low prices.



2. Professional Technical Team:

We can offer comprehensive solution for your projects.

We can offer detailed pre-sales requirements analysis and guide.

We can offer professional remotely technical support for problems.


3. Flexible Customization: We can customize software, firmware for customers requirements.

4. OEM,ODM service: We can design and produce machines with your own logo.

5. Good Service: We treat clients as good friend.

6. Special offers: We have special offers for long-term cooperation clients.



Payment Terms

1. Paypal or Escrow for small sample orders

2. T/T (Telegraphic Transfer)  or  Western Union / Moneygram

3. L/C(Letter of Credit) for high value orders

4. Cash for face to face business



Shippment Method

1. International Express(DHL, TNT, Fedex, UPS, EMS, Aramex), take about 3-7 days

2. International Airline, take about 5-15 days differently.

3. International Sea Shipping, slow but cheap for heavy goods, take about 10-50 days differently.

4. by POST , slow but cheap for small package, take 10-60 days.



Product Warranty

We provide 1~2 years warranty from the date of delivery but lifetime technical support.
