Automatic parallel paper tube winding machine

Specifications

Parallel paper tube winding machine SKPJ1640

Technology features:

1. Raising roll paper pattern: electrical machine automatically raises paper

2. Directly make the roll paper into the long paper tube

3. The end of the paper adds the water automatically and will not spring

4. The paper is automatically scraped the glue two times.

5. Vessels of storing and sliding the glue are all adopted the stainless steel plate, endure acid and corrosion

6. All operations are adopted numerical control design-PLC, realize full-auto  operation

7. The electrical and pneumatic spare parts are all used the World famous   enterprises' products and durable used

8. All the rewinding spare parts which are possible to touch the glue are adopted the wear-resisting alloy copper

9. Realize the unmanned operation

Tube inner diameter: 16-40mm

Operation required: 1 person control 2 machines

Tube thickness: 2.5-10mm

Paper thickness/max diameter: 300-400g/1100

Tube max length: 1220mm/1820mm

Power: 2.2kw+3*0.75 kw, 220/440/380V, 50/60HZ

Working frequency: 8~12 times/min

Outside dimension: 5380*1580*1300mm

Applicable paper grammage: 280gsm-600gsm
