Home > Products > 5.Level transmitter > submersible liquid level sensor QYB201
submersible liquid level sensor QYB201
USD $60 - $120
/ Piece
1 Piece(Min.Order)
- 5000 Piece / Pieces per Month
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
New 913A0124H01 York FRICK low-pressure pressure sensor, pressure range 0-200psi
-
New 913A0124H02 York FRICK high-pressure pressure sensor, pressure range 0-500psi
-
HBM S Type S9M Force Load Cell
-
HBM CFT+ Force Sensor
-
HBM C15 Force Transducer With 4MV/V Signal Output
-
HBM CFT Series Piezoelectric Force Transducer
Product Details
| Place of Origin: | Shaanxi, China | Brand Name: | QX | Model Number: | QYB201 |
Product Description
Specifications
Specifications1.Submersible type,
2.1.5 year warranty,
3.For water and other liquids,
4.OEM order ok,0-200m cable.
Submersible Type Liquid Water Level Transmitter with or without LCD Display
Product Description
Features:
0.25%,0.50% accuracy
-40ºC to 100ºC operating temperature
100% stainless steel 316L isolation.
Wide variety of pressure ranges and electrical outputs
Low cost and compact package
stainless steel with rigid and robust construction.
The protection cap with a small hole
The exquisite sealing technology
a waterproof cable with vent hose
Specifications:
| pressure range | 0~1mH2O...200mH2O |
| overload pressure | 200%FS |
| output signal | 4~20mA, 0~5V, 0~10V, 1~5V |
| accuracy | 0.1%FS, 0.25%FS (standard), 0.5%FS |
| load resistance | RL = (U-12V)/0.02A (4~20mA current output) U-loop voltage (V) |
| long term stability | <0.2%FS/year |
| supply voltage | 12~36V |
compensated temperature range | 0~70°c |
| storage temperature range | -40~+100°c |
| temperature coefficient of zero | 0.25%FS/10°c |
| temperature coefficient of span | 0.25%FS/10°c |
| insulation resistance | 100MΩ@ 50VDC |
| electrical connection | 7.6mm shielded cable with vent hose |
material of wetted part and housing | 1Cr18Ni9Ti |
| material of pressure membrane | 316L or tantalum |
| sealing | Butyronitrile or fluoro-rubber sealing ring |
Packaging & Shipping
FAQ
In order to offer the most suitable sensor , please give following necessary details:.
1.what is your medium and application?
2.what is your requirements for following specifications:
pressure range,output signal,electronic connection and accuracy
