PE PP Film Two-stage Ganulation Line
Application:
Plastic pellet making machine is one stage plastic regenerative pelletizer, which is suitable for many kinds of plastic waste materials recycling and making pellet, such as PP, HDPE, LDPE, LLDPE Film and clean woven/nonwoven bag materials, etc. The film can be pressed in compressor and then be pelleted.
System Configuration
Processing capacity can be 100-500kg/h
PE PP Film Two-stage Ganulation Line ---include:
1.Conveyor&Metal detector
2.Compaction warehouse.
3.Long single screw extruder:38CrMoAlA with nitriding processing
4.Hydraulic change nets equipment
5.Short screw extruder:38CrMoAlA with nitriding processing
6.Pelletizer:Two type----Water-ring Pelletizing Machine or Braces particle cutting machine
7.Dewatering Machine
8.Fan drying machine & Hopper
PE PP Film Two-stage Ganulation Line ----chart:
PE PP Film Two-stage Ganulation Line --- data sheet::
|
Model
|
GS-100/100 |
GS-120/120 |
GS-150/150 |
GS-180/180 |
GS-200/200 |
Main extruder | |||||
|
L/D
|
25-30 |
25-30 |
25-30 |
25-30 |
25-30 |
|
Main motor power(kw)
|
45-55 |
55-75 |
75-90 |
90-110 |
160 |
|
Heating power(kw)
|
40 |
45 |
55 |
70 |
90 |
|
rotation speed (RPM)
|
0-120 |
0-120 |
0-110 |
0-110 |
0-110 |
Sub-extruder | |||||
|
L/D
|
10-15 |
10-15 |
10-15 |
8-15 |
8-15 |
|
Motor power (kw)
|
22 |
30 |
37 |
45 |
75 |
|
Heating power (kw)
|
25 |
30 |
35 |
45 |
55 |
|
Rotation speeed (RPM)
|
0-120 |
0-120 |
0-110 |
0-110 |
0-110 |
|
Output (kg/hr)
|
150 |
200-220 |
300-350 |
400 |
500-600 |
After Service:
We have 1 year warranty, and lifetime maintenance.
Within one year, if there is some accessory going wrong, we will send you the accessory at once, free of charge.
1). Within one month, if the machine is of any big fails, we will send you a new machine.
2). Within one year, if you send back the equipment for repair, we will be responsible for the repair, including the changes of accessories; Both of them are free of charge.
3). After one years, we offer to repair the machine, but we quire for the cost of the changed parts, not for manual cost.
4). No responsibility for man-made destroy.
5). If the buyer has any questions from our technical department, we can supply on-line service Or we can send professional engineers to help you debug them
If you are interested in our machine,please feel free to contact us.
Thanks and best regards.
