Specifications
Working on leather, acrylic, wood, plastic, bambooHigh speed cutting
Steady large power
CE FDA
80W, 100W long life
laser equipment QX-1620
Main features:
1) DSP offline control system which can not only work without computer, but also connect to U disk, USB communication
2) USB interface.
3) Exclusive no water warning and automatic protection system, to protect the working life of laser tube effectively
4) The power control system has exclusive automatic protection equipment to ensure the stability and safety of the machine to the best
5) LCD control panel in English convenience of operation control
6) Import liner bearing with high engraving precision
7) Software: Lasercut software, direct output from Coreldraw and Autocad.
Specification | |||
Model |
QX1620 |
||
Working area |
1600*2000mm |
||
Laser Power |
80W(optional: 60w, 100w, 130w 150w) |
||
Laser Type |
CO2 sealed glass Laser Tube |
||
Engraving speed |
25-60000mm/min |
||
Cutting speed |
0-24000mm/min |
||
Driving system |
stepper |
||
Resetting positioning accuracy |
0.01mm |
||
Location precision |
≤0.01mm |
||
Minimum Shaping Character |
1×1mm |
||
Power supply |
220V±10% 50HZ or 110V±10% 60HZ |
||
Software supported |
ArtCut, CorelDraw, PhotoShop, AutoCAD |
||
Graphic format supported |
BMP CIF JPEG TGA TIFF PLT AL DXF DST(TIANDAO Embroidery Software) DWG CDR |
||
Water Cooling(Yes / No) |
Yes |
||
Laser Tube (life hours) |
1200-1500 hours |
||
Assistant Equipment |
Water pump |
Air pump |
Exhaust fan |
Optional Parts |
Red dot pointer |
Water chiller |
Honeycomb cutting table |
Consumables |
Lens and mirror, laser tube |
||
Certificate |
CE |
||
TERMS & CONDITIONS:
1. PAYMENT TERMS: By T/T
2. DELIVERY TIME: Max. 7 -10 days after your order
3. PACKING: Seaworthy Packing
4. PRODUCT OF ORIGIN: P. R. China
5. PRODUCT GUARANTEE PERIOD: Twelve Months for every part of machine, 6 months for laser tube and lens
After-sales service:
CD, Video, User Manual to guide how to install, operate our machine.
Application Field
Applicable materials: wood, bamboo, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass and other nonmetal materials
Applicable industries:
advertisement, gift, shoes, toys, computers, garments, model cutting, building, packaging, paper industry
