Kneading Machine
1. Different kinds of Kneading Machine for chewing gum and small candy making
mixer machine with base part
mixer machine with base part
Structure Chart of The Kneaing Machine small candy making machine
mixer machine with base part
Kinds of Kneading Machine provided.
Mainly include:
1). Hydraulic lid off (For small amount production).
2). Hydraulic tilting (Referring to the parameter).
3). The bottom bumping (Automatic operation or mass production recommended).
3). Laboratory Kneading Machine for testing.
mixer machine with base part
2. Applicationof the Kneading Machine :
mixer machine with base part
Kneading machine is widely used for the raw material mixing of Ink, Eraser, Silicone sealant, Plasticine, Gum and other high viscosity materials.
mixer machine with base part
3.Features of The Kneading Machine :
1). With no dead spot, Kneading Machine works high-efficiency in mixing, kneading, crushing and dispersing for viscous materials.
2). Inverter for frequency control.
3). Vacuum or Forcing are available.
4). Two sigma or Z-type blades.
5). Discharge mode: Hydraulic lid off, Hydraulic tilting, Bottom pumping.
6). Jacketed electric heating or cooling.
7). Items are made of stainless steel.
mixer machine with base part
4. Technical specification of the Kneading Machine
|
Model
|
Volume (L) |
Drive motor power (KW) |
Mixing Speed (rpm) |
Discharge mode |
Heating |
|
||||
Full volume |
Feeding amount |
Paddle fast / slow paddle |
Optional parameters |
Optional parameters |
||||||
NHZ-5 |
5 |
3 |
2.2-4 |
75/50 |
Manual / Hydraulic tilting |
Running Hot oil |
Electrical heating |
Pressure Steam |
||
NHZ-20 |
20 |
12 |
3-5.5 |
63/42 |
||||||
NHZ-50 |
50 |
30 |
4-7.5 |
63/42 |
||||||
NHZ-100 |
100 |
60 |
5.5-7.5 |
43/29 |
||||||
NHZ-200 |
200 |
120 |
7.5-15 |
43/29 |
Hydraulic tilting |
The bottom pumping |
Screw extruding |
|||
NHZ-300 |
300 |
180 |
11-18.5 |
43/29 |
||||||
NHZ-500 |
500 |
300 |
18.5-30 |
43/29 |
||||||
NHZ-1000 |
1000 |
600 |
22-55 |
32/22 |
||||||
NHZ-1500 |
1500 |
900 |
30-90 |
32/22 |
||||||
NHZ-2000 |
2000 |
1200 |
45-110 |
32/22 |
||||||
NHZ-3000 |
3000 |
1800 |
55-130 |
33/22 |
||||||
|
Remarks: 1.Temperature range: 0-300°, 2. Pressure range:-0.1-0.6MPa, 3. Inverter for frequency control if necessary. | ||||||||||
mixer machine with base part
5.OUr production line
mixer machine with base part
6. Packing and Shipping
l Standard Export Packing
l FOB (usually), CIF, CFR
mixer machine with base part
7. Warranty and after-sale services
- 18 months' free of charge warranty for all of our machines except of the pipes, valves, pumps etc.
- Customer request for product modification or new product development are invited.
- 24 hours technical support by Email, Skype, Mobile-phone
- Engineers are available to overseas for technical support or producing guidance.
- Original manufacturers' price for quick-wear parts of our machines.
mixer machine with base part
8. About Us
Our Website: http://gdjct.en.china.cn
mixer machine with base part
9. Office and Clients
mixer machine with base part
10. Certificate
mixer machine with base part
11. FAQ
mixer machine with base part
12. Contact information
