KS-85T-RVV Vertical Injection Molding Machine

Name: KS-85T-RVV Vertical Injection Molding Machine
Brand: Kasun
SKU: 118836823

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Application:

Other

Plastic Processed:

EPS

Dongguan Jiaxingchang Mechanical Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Other

Plastic Processed EPS

Automatic Yes

Place of Origin Guangdong, China

Brand Name Kasun

Model Number KS-85T-RVV

Voltage 380V

Dimension(L*W*H) 2.3*2.0*3.1m

Weight 6.5tons

Certification ISO9000

Specifications

1.vertical injection molding machine
2.Injection Pressure:1742kg/cm3
3.automatic,high speed,safety
4.MOQ=1
5.ISO9000

KS-85T-RVV vertical injection molding machine

Bircolor Disk Unit

Description of products:

Vertical mold clamping, externally added disk, supporting two separated injection systems, two upper molds installed on upper platen and two (three)lower molds installed on disk, bicolor(double material) or wrapping molding can be accomplished as the table rotates positively and reversely by 180C alternating.
Highly efficient disk, driven by gears, self lubricating, antiwear, copper fake bearing, fast rotation, accurate positioning, chrome-coated surface with anti-rust performance, good appearance and long durability.
4+4-section temperature control, multi-section injecting, pressing and pressure retaining, injection velocity adjusted.
Combined or separated structure optional for clamping unit, 2-station standard disk, 3 or 4 stations optional if required, bringing more convenience for operations
Fully computerized double electric ruler control, automatic alarm, easy for eliminating failures and maintenance work, machine can be equipped with automatic inlaying or taking-out device to raise production capacity, with clamping force of 85T-400T.
Suitable for multi-color molding in eyeglasses and shies industries.

Specification:

Model

Unit

KS-85T-R

Number of Temperature Control		4+4
Clamping Force	Tons	85
Opening Force	Tons	16
Platen Size	mm	*12501250**
Distance Between Tie Bare	mm	920*570
Min.Mold Height	mm	220
Oprening Stroke	mm	215
Ejector Force	Tons	1.5
Ejector Stroke	mm	125
Max.Hydaulic Pressure	Kg/cm³	140
Pump Output	Liters/min	97+56
Pump Motor Power	kw/HP	18/25
Barrel Heating Power	kw	6.5
Machine Weight	Tons	4.9
Machine Dimensions(L×W×H)	m	2.32.03.1
Shipping Measurements(L×W×H)	m	2.52.23.3
