Home > Manufacturing & Processing Machinery > Plastic Machinery > Injection Molding Machine > KS-120T Auto Plastic Injection Molding Machine
KS-120T Auto Plastic Injection Molding Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Preform Injection
Style:
Vertical
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KS-35T Small Injection MachineUS$ 7,131 - 7,293MOQ: 1 Set -
Tpye KS-25T Injection Molding Machine for Small Electric DeviceUS$ 5,024 - 5,200MOQ: 1 Set
-
KS-15T Injection Moulding MachineUS$ 3,889 - 3,990MOQ: 1 Set
-
KS-25T Small Plastic Moulding MachineNegotiableMOQ: 1 Set
-
2015 NEW KS-120T Vertical Injection Moulding Machine for Baby Nipples MakingNegotiableMOQ: 1 Set
Condition
New
Type
Preform Injection
Style
Vertical
Brand Name
kasun
Model Number
KS-120T
Place of Origin
Guangdong, China
Plastic Type
Thermoplastic
Automatic
Yes
Injection Weight
152-261g
Injection Rate
76-130cm3/sec
Clamping Force
120tons
Opening Stroke
230mm
Power(W)
22.3kw
Certification
ISO9000
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.auto plastic injection molding machine2.factory built:in 1996
3.address:shatou district,changan town ,dongguan
KS-120T vertical plastic injection machine
Injection section:
double guiding rod supporting
double dro-cylinder balance injection
Computer-control:
PLC control
improved precision to due to faster speed control system
automatic alarm
digital memory for mold group
Hydraulic unit:
Japan YUKEN
system pressure is controlled through proportional
Clamping unit:
fine-element analysis used to design platen
adjustable mechaical support system used for moving platens to protect tie bars
Other parts:
shot counter and reset function
malfunction alarm light
self-diagnostic function
emergency stop buttons placed both front and rear of the machine for easy access
blotter filter
Configuration table
| Oil pressure spares: | ||||||||
| oil pump | Taiwan Hai Teke Hydraulic CO.,LTD. | |||||||
| oil motor | U.S. WHITE Group | |||||||
| electromagnetic selector valve | Japan YUKEN CO.,LTD. | |||||||
| proportional valve | Japan YUKEN CO.,LTD. | |||||||
| semi-closure valve controller | Germany Dr.Rexroth INC. | |||||||
| hydraulic valve | Taiwan Hai Teke Hydraulic CO.,LTD. | |||||||
| Electric spares: | ||||||||
| computer controller | Procheson Technology CO.,LTD. | |||||||
| temperature sensing wire | Taiwan Arico CO.,LTD. | |||||||
| SSR | Taiwan Yangming CO.,LTD. | |||||||
| electric ruler | Switzerland Mrian CO.,LTD. | |||||||
| power switch | Mitsubishi | |||||||
| Others: | ||||||||
| electronic motor | Global Electric Machinery LTD. | |||||||
| sealing | Japan NOK Joint-Stock-Cooperation | |||||||
| feed pipe group | Taiwan Tianxing CO.,LTD. | |||||||
| tie bar | Taiwan Jiangjun Machinery CO. | |||||||
| oil pipe | Italy ALFA CO. | |||||||
| oil cylinder | Taiwan Jiangjun Machinery CO. | |||||||
| Model | Unit | KS-120T |
| Screw Diameter | mm | 32 | 36 | 42 |
| Injection Pressure | Kg/cm² | 3445 | 2722 | 2000 |
| Theoretical Shot Volume | cm³ | 165 | 208 | 284 |
| (ps) Max.shot Weight(ps) | G/oz | 152 | 191 | 261 |
| Injection Rate | cm³/sec | 76 | 95 | 130 |
| Number of Temperature Control | 4 | |
| Clamping Force | Tons | 120 |
| Opening Force | Tons | 16 |
| Platen Size | mm | 950*740 |
| Distance Between Tie Bare | mm | 610*470 |
| Min.Mold Height | mm | 180 |
| Oprening Stroke | mm | 230 |
| Ejector Force | Tons | 2.3 |
| Ejector Stroke | mm | 50 |
| Max.Hydaulic Pressure | Kg/cm² | 140 |
| Pump Output | Liters/min | 112 |
| Pump Motor Power | kw/HP | 15/20 |
| Barrel Heating Power | kw | 7.3 |
| Machine Weight | Tons | 4.5 |
| Machine Dimensions(L×W×H) | m | 3.53*1.67*3.1 |
| Shipping Measurements(L×W×H) | m | 3.75*1.9*3.2 |
