2015 Fully Auto Foam peeling machine
- 20 Set / Sets per Month
- ShenZhen Port
- T/T L/C D/P D/A Credit Card PayPal
- Lightweight thermal insulation house prefabricated wall panel price
- Mgo Sound insulation and heat preservation concrete hollow lightweight partition wall panels
- lightweight partition wall panel
- building material Mgo precast wall panels
- Mgo lightweight concrete foam wall panels Quality Choice
- Supply perforated/acoustic/sound-absorb wall panel mgo board/fireproof mgo board/magnesium oxide board
Product Details
Condition: | New | Place of Origin: | Guangdong, China | Brand Name: | EliteCore Machinery |
Model Number: | ECMT-123 | Voltage: | 3phase,380v,50hz/60hz | Power(W): | 6.5kw |
Weight: | 2000kg | Certification: | CE | Warranty: | One Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Foam peeling machine
This Machine is used to Peel Round Foam Blocks Into Continuous Long Sheets,It can Winding & Metering Into Rolls According to Customer’s Rquests,This Machine must be used together with ECMT-124/124B/125 Foam Boring Machine,The finished Foam Rolls can be used for market directly,Or For Further Lamination Works of Foam Laminating Machines,Or For Further Mattress Cover Quilting of Quilting Machines.
SPECIFICATION:
ECMT-123 | |
Cutting Foam Size: | Dia2000mm*W2150mm |
Cutting Speed: | 0~50m/min(Adjustable)
|
Cutting Blade Size:
| L8985mm*W30mm*T0.45mm |
Rewinding Speed: | 0~50m(Adjustable) |
Cutting Thickness Range: | 2mm~25mm |
Cutting Thickness Adjustment:
| Adjust Thickness Wheels By Manual.
|
Control Type:
| Automatic Electric Control.
|
Machine N.W:
| 2000kg |
Total Motor Power:
| 6.5kw |
Floor Space:
| L4800mm*W1750mm*H1700mm |
