NEMA air cooler ac motor

Specifications

NEMA ac motor,
CCC,CE,ISO9001,ROHS, EFF2,
this kind of electric motor are made in NEMA Standard with light weight,

NEMA ac motor



this kind of electric motor are made in NEMA Standard, it  is with  light weight, better proformance, high effiency, they are widely used.
Specifications:
1) Frame sizes: 56
2) Rated power: 0.75 kW
3) Rated voltage: 110 - 120V, 200 - 240V
4) Frequency: 50Hz, 60Hz
5) Protection class: IP24
6) Insulation class: F
7) Materials: steel
8) EFF: EFF2
9) Poles: 2
10) speed:3410 RPM
11) Cooling method: ODP (open drip proof)
12) Mounting types: IMB3
13) Operating mode: S1
14) Ambient temperature: -35°C < θ< 40°C
15) The altitude should be lower than 1,000m above the sea level
16) Relative humidity: not higher than 90%
17) Special motors can be designed according to customers' requirements
18) Export markets: Europe, North America, the Middle East, Africa, Southeast Asia,
East Asia, South America
