Sponge foam make machine
Parameters:
Mixing Tank Capacity: |
180L~250L |
Mixer Total Power: |
11KW |
Mixing Speed: |
2800r~4200r/min |
Save Formular Q.T.Y.: |
20 Groups. |
Control System: |
PLC Touch Screen Control System |
PPG Tank: |
3Ton*1Set. |
POP Tank: |
3Ton*1Set. |
TDI Tank: |
2Ton*1Set. |
MC Tank: |
1Ton*1Set. |
Air Valves: |
Euro Standard |
Auto Loading Pumps For PPG,POP,TDI,MC: |
4Sets(“Line”Brand Made In China) |
Small Chemical Tanks & Pumps: |
4Sets |
Chiller(Both Cooling & Heating System): |
1Set*15KW(Made InTaiWan) |
Oil Hydraulic System: |
1Set |
Air Compressor: |
1Set*7.5KW |
Electric Float Top System: |
1Set(Electric) |
Auto Cleaning System: |
1Set |
Air Filtering System: |
1Set. |
Water Tower: |
1Set |
Water Pump: |
1Set. |
FoamingDensityRange: |
8~50kg/Cubicmeter. |
Outputs: |
96 Blocks/per day/8hrs(480m3/day) |
Match WithOne SquareMould: |
L2100mm*W2100mm*H1300mm(To Be Requested) |
Match With One Cylinder Mould: |
Dia1800mm*H2200mm(To Be Requested) |
Total Motor Power: |
Approx 35KW. |
Machine N.W.: |
Approx 6Ton |
Floor Space Required: |
L10m*W10m*H6m. |
Foam/Sponge producing machine with pneumatic motion, which can be used with Rectangular, Cubic and Cylindrical Molds. The speed of the Mixer can be controlled electronically from control panel. The small Raw-Materials are put in to the Tank manually. Its products used in Bed, Furniture and all kind Sponge Producing Factories.
Application :
Foam industry ;sponge industry ;furniture industry ;sofe factory ;furniture factory.shoes factory .
Images :
Package: Wooden Box & Hard Paper Film Packing
Shiping: by sea & by air &by express(DHL,UPS,EMS,Fedex etc)
1. Your inquiry for our products will be replied in 24 hours
2. Well-trained and experienced employers to answer all your questions
3. Protection of your sales area, ideas of design and all your private information.
EliteCore Machinery Manufacturing Co.Ltd is one of professimal manufacturers with design,manufacture and sales polyurathane foam machinery. Our products are exported to more than one hundred countries such as: America ,Europe and Southeast Asia, especially we sold dozens of Fully Automatic Continuous Foaming Machine to Romania, Argentina, Croatia, UAE, Jordan,Nigeria,Turkey,Egypt,Zambia,Dubai,Greece,Saudi Arabia, Brazil, Uzbekistan,
India, Korea, South Africa etc !
Our Mission is to Deliver the Right Product at the Right Price at the Right Time,With Our Genuinely Service to Get Your Money’s Worth.
Exhibition :
Customers:
Q: Does your machine have CE certification?
A: Yes,our machine with CE certification.
Q: How about payment terms?
A: 30% TT deposit + 70% TT before shipment,50% TT deposit + 50% LC balance, Flexible payment can be negotiated.
Q: Do you offer turn-key solutions?
A: Yes, we provide consultancy service and turn-key solutions.
Q: Installation and commissioning?
A: We will send our engineer for installation and commissioning, but relevant cost will be paid by you.
Q: Do you have some videos where we can see the line producing?
A: Yes, we can provide some videos for reference.
