UPVC Pipe Extrusion Line
1. Mixture material: PVC+CaCO3+CPE+Wax...
2. Screw Type: twin screw
3.Capacity: 250kg/h
4.Speed: 1-8m/min
5. Inverte Control
Decription:
This line is a fully automatical production line, with main extruder of SJSZ51/105 series or SJSZ65/132 series or SJSZ80/156 series or SJSZ92/188 series for different diameter's pipe. pvc pipe machine with price The products of this line---PVC pipe is used for drainage pipe and water supply pipe, the out diameter range for pipe is 12 - 630mm. raw material is pvc powder extruder type: twin screw extruder machine output: 120-400kg/h; In the production line, can attach PVC mixer, Crusher, Pulverizer.
Technical parameter:
Model |
SJSZ-51 |
SJSZ-55 |
SJSZ-65 |
SJSZ-80 |
SJSZ-92 |
Screw dia.(mm) |
51/105 |
55/110 |
65/132 |
80/156 |
92/188 |
Max speed(rpm) |
40 |
38 |
38 |
37 |
36 |
Main motor(KW) |
18.5 |
22 |
37 |
55 |
90 |
Output(KG/H) |
80-100 |
100-150 |
150-250 |
250-380 |
380-700 |
Centre height(mm) |
1050 |
1050 |
1050 |
1050 |
1100 |
Net weight(KG) |
3000 |
3500 |
4000 |
5500 |
8000 |
L*W*H(m) |
3.6*1.1*2.1 |
3.6*1.1*2.1 |
4.2*1.5*2.4 |
4.7*1.5*2.4 |
6*1.6*2.5 |
PVC Pipes Picture:
