CMM generator set
- 30 Set / Sets per Month
- Qingdao
- T/T
Product Details
Place of Origin: | Shanxi, China | Brand Name: | LVHUAN | Model Number: | LHCG500 |
Output Type: | AC Three Phase | Speed: | 1000/1200rpm | Frequency: | 50/60Hz |
Rated Power: | 500kw | Rated Voltage: | 400/230V | Rated Current: | 910A |
Product Description
Specifications
coal mine methane genset1, Eary to operate
2. 25000 hours overhaul
3. ISO9001, ISO14001 and CE
coal mine methane generator set
Main technical paremeters:
Parameter of coal gas Generator Set | |
Model Number (Engine Type) | LHCG500 |
Brand Name | LVHUAN |
Prime Power/Standby Power | 400KW/500KW |
Rated Speed | 1000/1200rpm |
Rated Frequency | 50/60Hz |
Rated Voltage | 400V/230V |
Phase | AC 3-Phase, 4 wire |
Voltage Stability | ≤±2% |
Voltage transient | ≤±10% |
Voltage Stable time | ≤1 |
Heat consumption | ≤9.8mj/kw.h |
Lubricant Consumption | ≤1.0g/kw.h |
Engine Capacity | 71.6 L |
Cylinder Number | 12-V |
Cylinder Bore | 190mm |
Stroke | 210mm |
Starting System | DC 24V electic motor |
Cooling method | water cooler |
Lubricant method | Passive and flying lubricant |
Isolation class | H |
Protection | IP23 |
Alternator | Siemens |
Power Factor | 0.8 lagging |
Exciting method | brushless |
Colour | your choice |
Certificates | ISO 9001, ISO14001, CE |
Warranty | 1 year or 1000 running hours |
Type | Open |
Control system | ATS and AMF |
Function | Automatic alarm system |
Size | 6200x2100x2800mm |
Weight | 12500kg |
