| Item | Parameter |
|---|---|
| Cylinder No. | V20 |
| Bore | 190 mm |
| Stroke | 255 mm |
| Power | 2000/1800 kW |
| Speed | 1000/1200 rpm |
| Fuel | Natural gas/Associate gas/Coalbed methane gas/Biogas |
| Voltage | 400V/480V/6300V/10500V/13800V |
| Frequency | 50Hz/60Hz |
| Power factor | 0.8 |
| Weight | 28000 kg |
JICHAI 2000GF-T gas generator sets are designed to be high quality, with a long usage life, easy operation, low maintenance cost, high intelligence, low engine speed, low fuel consumption, low gas quality requirement, tough environmental adaptability, high stability, and low fluctuation。The generator sets are desirable for industrial power solutions。
The main specifications of the JICHAI 2000GF-T gas generator sets include a rated power of 2000 kW/2500 kVA, with a rated voltage of 10.5 kV。The rated speed is 1000 rpm, and the rated frequency is 50Hz。The power factor is 0.8 lagging，and the control mode is electric control。The generator set has a close type water cooling mode and a net weight of 28000 kg。
The gas engine model for this generator set is L20V190ZLT-1, which features a 20-cylinder, V-type configuration with a 60° included angle。It is a four-stroke, closed type water-cooled, turbocharged engine with electronic ignition and electronic speed governor。The bore and stroke measurements are 190 mm and 255 mm, respectively，and the engine requires an intake gas pressure of 100-400 kPa before the gas pressure regulator。
