400kw Syngas Generator Set
US$ 12,000 - 20,000
/ Set
1 Set(Min. Order)
- Qingdao
- T/T Money Gram
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | LVHUAN | |
| Model Number | LHSG400 | Type | Other, Syngas generator set |
Product Description
Specifications
1.Advanced equipment protecting system2.ISO9001:2008 and CE certification
3.Friendly to the environment.
4.Low noise level
Ignition system:We adopt ignition system of magneto which produced by American ALTRONIC company,including:magneto,high-tension coil,sparking plug.
Starting system: DC24V electric motor,12v190 adopt ST710 of direct-current.
Pressure charging system:Pulse Mixed-flow supercharger, compression ration is 1:8,meet engine's requirement for gas-flow rate.
Speed regulating system:EGS gas controller of American WOODWARD Company.
Scope of application:Biogas generator set is widely used in the many area where can generate biogas,like rubbish landfill,livestock excrement disposal,industrial organism disposal.
| Parameter of 400kw Methane Generator Set | |
| Model Number (Engine Type) | LHM400 |
| Brand Name | LVHUAN |
| Prime Power/Standby Power | 320KW/400KW |
| Rated Speed | 1000/1200RPM |
| Rated Frequency | 50/60Hz |
| Rated Voltage | 400V/230V |
| Phase | AC 3-Phase, 4 wire |
| Voltage Stability | ≤±2% |
| Voltage transient | ≤±10% |
| Voltage Stable time | ≤1s |
| Heat consumption | ≤9.8mj/kw.h |
| Lubricant Consumption | ≤1.63g/kw.h |
| Engine Capacity | 71.4 L |
| Cylinder Number | 12-V |
| Cylinder Bore | 190mm |
| Stroke | 210mm |
| Starting System | DC 24V electric motor |
| Cooling method | water cooler |
| Lubricant method | Passive and flying lubricant |
| Isolation class | H |
| Protection | IP23 |
| Alternator | Siemens |
| Power Factor | 0.8 lagging |
| Exciting method | brushless |
| Colour | your choice |
| Certificates | ISO 9001:2008, CE |
| Warranty | 1 year or 1500 running hours which arrives first |
| Type | Open |
| Control system | Automatic alarm system |
| Function | ATS and AMF |
| Size | 6200x2100x2650mm |
| Weight | 12000kg |
