STBA22 Seamless Alloy Steel Pipe
- xingang
- T/T Credit Card PayPal
You May Like
Product Details
| Thickness | 2, 100 | Section Shape | Round | |
| Outer Diameter | 16 - 824 mm | Place of Origin | Tianjin, China | |
| Secondary Or Not | Non-secondary | Application | Boiler Pipe | |
| Technique | Hot Rolled | Certification | Other, BUV | |
| Surface Treatment | Copper Coated | Special Pipe | Thick Wall Pipe | |
| Alloy Or Not | Is Alloy |
Product Description
STBA22 15CrMo seamless alloy steel pipe
Product Name | GB5310 15CrMo seamless alloy steel pipe |
Standard | DIN17175, JISG3467, JISG3458, GB5310-2008, GB9948-2006, ASTMA335/A335M, ASTMA213/A213M |
Main Material | 12Cr1MoVG,15CrMoG(A335 P11,A335 P12, STBA22),1Cr5Mo(A335P5) , 10CrMo910(A335 P22) 10Cr9Mo1VNbN(A335 T91 A335 P91),10Cr9MoW2VNbBN (A335 T92 A335 P92) , Cr9Mo(A335 P9),13CrMo44,25CrMo,30CrMo,40CrMo, 16MnDG,10MnDG,09DG,09Mn2VDG,06Ni3MoDG, ASTM A333Grade(1,2,,3,,4,5,6,,7,8,9,10,11) |
Application | Petroleum, chemical industry, electricity, boiler industry etc |
Surface treatment | With anti-rusting paint or as requested |
Outer Diameter | 16-824mm |
Wall thickness | 2-100mm |
Length | 5.8 Meters, 6 Meters, 11.8 meters or as requested |
Delivery time | We have some pipes in stock or about 15 days after receiving deposit or according to the order quantity. |
Packages | To be packed in bundles by steel strips or as requested |
Port of Dispatch | Xingang China or as requested |
Third Party Inspection | We accept third party inspection like SGS, but will need your side to pay the charges. |
Samples | We have samples for most of the products. The samples will be free, but will need you to pay freight charges. |
Our products | Stainless steel, carbon steel, alloy steel, Aluminum etc ( Pipes, plates, bars, coils, strips) etc |
Contact | Miss Jessica Skype: jessicaluo2016 |
GB5310 15CrMo seamless alloy steel pipe
GB5310 15CrMo seamless alloy steel pipe
| Room temperature mechanical properties | ||||
standard number | steel grade | σs | σb | δs | αk |
(MPa) | (MPa) | (%) | (J/cm2) | ||
GB5310 | 12CrMo | 206 | 412~559 | 21 | 69u |
| 15CrMo | 235 | 441~638 | 21 | 59u |
| 12Cr1MoV | 255 | 471~638 | 21 | 59u |
| 12Cr2Mo | 280 | 450~600 | 20 |
|
ASTM A335 | P1 | 207 | 379 | 22 |
|
| P11 | 207 | 413 | 22 |
|
| P12 | 207 | 413 | 22 |
|
| P2 | 207 | 379 | 22 |
|
| P22 | 207 | 413 | 22 |
|
| P5 | 207 | 413 | 22 |
|
| P9 | 207 | 413 | 22 |
|
DIN17175 | 19Mn5 | 300~310 | 510~610 | 19 |
|
| 13CrMo44 | 280~290 | 440~590 | 22 |
|
| 14MoV63 | 310~319 | 460~610 | 20 |
|
| 10CrMo910 | 269~280 | 450~600 |
| |
GB5310 15CrMo seamless alloy steel pipe
Item | Details |
Alloy Steel Pipe | 12CrMoVG, 15CrMoG(A335 P11, A335 P12, STBA22), 1Cr5Mo(A335P5), 10CrMo910(A335 P22), A335 T91, A335 P91, A335 T92, A335 P92, A335 P9, 13CrMo44, 25CrMo, 30CrMo, 40CrMo etc |
Low temperature pipe | 16MnDG, 10MnDG, 09DG, 09Mn2VDG, 06Ni3MoDG, ASTM A333 Grade (1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11) |
High-Pressure boiler tubes | 20G,A106c, 15CrMoG(P11 T12 P12 STBA22) , 12Cr1MoVG, ST45.8/3, ASTM SA106B/C, ASTM SA210A/C |
Low middle pressure boiler tube | 10#, 20# |
Fluid pipelines | 10#, 20#, Astm A106A,B,C A53A,B 16Mn, Q345A,B,C,D,E |
Structural pipe | 10# 20# 45# Astm A53A,B 16Mn(Q345A,B,C,D,E) |
Line pipe | X42, X46,X52, X56,X60,X65,X70,X80,L245,L290, L360, L415, L450 etc |
Oil casing | API SPEC 5CT J55 K55 N80 L-80 P-110 |
Alloy steel materials | plate, pipe, coil, flat bar, angle bar, round bar etc. |
Aluminum materials | plate, pipe, coil, flat bar, angle bar, round bar etc. |
Carbon steel materials | pipe,angle bar, round bar etc. |
Stainless steel materials | plate, pipe, coil, flat bar, angle bar, round bar etc. |
Checker plate | Stainless Steel, Aluminum, alloy steel etc |
Other pipes | Copper pipes, brass pipes, Titanium pipes etc |
