Alloy Steel GB5310 Standard Heat Exchanger Tube

US$ 600 - 2,000 MOQ: 1 Ton

Key Specifications

Standard:

Grade:

Thickness:

2, 100

Tianjin A Large High-Pressure Alloy Pipe Sales Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

xingang china or as your requests

Delivery Detail:

Delivery time depends on order quantity.

Thickness 2, 100

Section Shape Round

Outer Diameter 16 - 824 mm

Place of Origin Tianjin, China

Secondary Or Not Non-secondary

Application Structure Pipe

Technique Hot Rolled

Certification Other, SGS

Surface Treatment Copper Coated

Special Pipe EMT Pipe

Alloy Or Not Is Alloy

Alloy steel GB5310 standard Heat exchanger tube

Product Description

Product Name	Alloy steel Astm A213 Gr T9 heat exchanger tube
Standard	DIN17175, JISG3467, JISG3458, GB5310-2008, GB9948-2006, ASTMA335/A335M, ASTMA213/A213M
Main Material	12Cr1MoVG,15CrMoG(A335 P11,A335 P12, STBA22),1Cr5Mo(A335P5) ,10CrMo910(A335 P22) 10Cr9Mo1VNbN(A335 T91 A335 P91),10Cr9MoW2VNbBN (A335 T92 A335 P92) , Cr9Mo(A335 P9),13CrMo44,25CrMo,30CrMo, 40CrMo, 16MnDG,10MnDG,09DG,09Mn2VDG, 06Ni3MoDG,ASTM A333Grade(1,2,,3,,4,5,6, ,7,8,9,10,11)
Application	Petroleum, chemical industry, electricity, boiler industry etc
Surface treatment	With anti-rusting paint or as requested
Outer Diameter	16-824mm
Wall thickness	2-100mm
Length	5.8 Meters, 6 Meters, 11.8 meters or as requested
Delivery time	We have some pipes in stock or about 15 days after receiving deposit or according to the order quantity.
Packages	To be packed in bundles by steel strips or as requested
Port of Dispatch	Xingang China or as requested
Third Party Inspection	We accept third party inspection like SGS, but will need your side to pay the charges.
Samples	We have samples for most of the products. The samples will be free, but will need you to pay freight charges.
Our products	Stainless steel, carbon steel, alloy steel, Aluminum etc ( Pipes, plates, bars, coils, strips) etc
Contact	Miss Jessica QQ: 1982468214 Skype: kayley520 Mobille Phone: +8618920213573

Alloy steel GB5310 standard Heat exchanger tube

		Room temperature mechanical properties
standard number	steel grade	σs	σb	δs	αk
standard number	steel grade	(MPa)	(MPa)	(%)	(J/cm2)
GB5310	12CrMo	206	412~559	21	69u
	15CrMo	235	441~638	21	59u
	12Cr1MoV	255	471~638	21	59u
	12Cr2Mo	280	450~600	20
ASTM A335	P1	207	379	22
	P11	207	413	22
	P12	207	413	22
	P2	207	379	22
	P22	207	413	22
	P5	207	413	22
	P9	207	413	22
DIN17175	19Mn5	300~310	510~610	19
	13CrMo44	280~290	440~590	22
	14MoV63	310~319	460~610	20
	10CrMo910	269~280	450~600

Our Services

Alloy steel GB5310 standard Heat exchanger tube

Some of our export experience

Country	Quantity	Grade	Material
Singapore	25 Tons	304, 316	Stainless steel pipes, stainless steel square pipes, stainless steel plate, stainless steel rod, stainless steel angle bar
South Korea	7 Tons	201	Stainless steel pipe
Vietnam	50 Tons	A335 P91, A335 Gr 6, 16MnDG	Alloy seamless steel pipe
Canada	30 Tons	6061 T6	Aluminum tubes
Russia Federation	45 Tons	321, 316	Stainless steel plates
Israel	2 tons	6061 T6	Aluminum pipes
India	1 ton	1050 H18 Anodized	Aluminum plate
Kenya	2 tons	6013	Welding electrodes
Singapore	50 Tons	S275, mild steel	Mild steel pipes, mild steel flat bars, mild steel square hollow section, mild steel plate
Oman	10 Tons	3105 F	5 Bars Aluminum checkered plate
Singapore	5 Tons	1100	Aluminum plate
