Three Phase Din Rail Multifunction Energy Meter

FOB Price

Negotiable / Piece

500 Pieces(Min. Order)

Port Shanghai or Ningbo
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	YTL
Model Number	D513001	Display Type	Digital Only
Phase	Three Phase	Measuring Energy Range	5(60)A
Accuracy Class	1.0	Output Voltage	3*230/400V
Operating Temperature	-20~50℃	Dimensions	122.511565

Product Description

Specifications

multifunction energy meter
1. RS485 communication and RF communication
2. With inside relay, current can reach 80A
3. Multifu

three phase din rail multifunction energy meter

As a professional manufacturer, YTL designs and produces e din rail smart meter which are cost-efficient and ideal for the use in solutions for AMR/AMI at residential as well as industrial applications.

YTL is devoted to develop and design all types of electronic din rail smart meter , concentrators and solution applications. With a combined design of the special accessories, we have successfully developed series of competitive products of small size, multifunction, low power consumption and excellent performance. We offer a one-to-one service to our partners. With annually over 68 projects that are successfully finished and holding over 200 patents of design rights, we are also advanced in the technology and patents of current sampling.

1.Product Details
Product Name		Three phase din rail multifunction energy meter
Installation type		Din-rail
Module No.		D513001 ( multifunction energy meter )
Brand		YTL ( multifunction energy meter )
Rated Current		5(60)A
Reference Voltage		3*230/400V
Frequence		50HZ
Display Mode		LCD 6+2
Accuracy		1.0
Impulse Constant		1600imp/kWh
Start Current		0.004Ib
Connection Mode		Direct type, CT type
Communication&Protocol		IEC1107
Power Consumption		2W
Material of meter case		ABS
Size		122.511565
Certificate		ISO9001
Standard		IEC62052-11, IEC62053-21
2.Functions and characteristic
A. Two direction active energy.
B. Reactive energy measurement.
C. Instantaneous kW,V,A,PF and MD
D. The time interval can be programmable between 1-60 minutes.
E. Active and reactive four tariff ,Total MD and MD for each tariff and save billings of last 12 monthes.
F. Record active and reactive load data for 127 days
G. .Meter can shift the display mode through button.Normal items can be chosen from the means as per required and the display intercal can be programmable
H. Meter has infrared and RS485 communication which can read and set meter parameters. All the billing data and electricity paramaters can be read.
I. Backlight is optional
3.Outer and mount dimension:

4.Wiring diagram:

*5.Transaction Information*
MOQ	300pcs
Sea Port	Shanghai
Payment Terms	T/T,L/C
Supply Ability	50000pcs/month
Delivery time	20-25 days after receive prepayment
Normal Package	white box
