Three Phase Electric Energy Meter

FOB Price

Negotiable / Piece

500 Pieces(Min. Order)

Port SHANGHAI

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	YTL
Model Number	D521001	Display Type	Digital Only
Phase	Three Phase	Measuring Energy Range	1.5(6)A
Accuracy Class	1.0,2.0	Output Voltage	3230/400V, 3220/380V
Operating Temperature	-30~+55℃	Dimensions	170mm72mm230mm

Product Description

Specifications

Three phase electric energy meter
1-CT type, constant is 12800imp/kWh
2-Counter display mode
3-CE certificate

Three phase electric energy meter

As a professional manufacturer, YTL designs and produces electric energy meters which are cost-efficient and ideal for the use in solutions for AMR/AMI at residential as well as industrial applications.

YTL is devoted to develop and design all types of electric energy meters, concentrators and solution applications. With a combined design of the special accessories, we have successfully developed series of competitive products of small size, multifunction, low power consumption and excellent performance. We offer a one-to-one service to our partners. With annually over 68 projects that are successfully finished and holding over 200 patents of design rights, we are also advanced in the technology and patents of current sampling.

1.Product Details
Product Name		three phase electric energy meter
Installation type		Suspension type
Module No.		D521001 (electric energy meter)
Brand		YTL (electric energy meter)
Rated Current		3*1.5(6)A
Reference Voltage		3110V; 3220V/380V; 3*230/400V
Frequence		50/60Hz
Display Mode		LCD
Accuracy		1.0
Impulse Constant		12800imp/kWh
Start Current		0.004Ib
Connection Mode		CT mode
Communication& Protocol		/
Power Consumption		≤1.0W;≤0.3VA
Material of meter case		PC
Size		170mm72mm230mm
Certificate		CE
Standard		IEC62052-11/IEC62053-21
2.Functions and characteristic
A. With simple structure and high reliability, the meter adopts three-chip synthetic technology and some certain constants can be decided by users.
B. Measure and calculate the accumulative active power with power indicator and energy indicator
C. With wide measuring range without hooks, shunt sampling is adopted to avoid tampering by pulling off the hooks or shunting direct current
…
3.Outer and mount dimension:

4.Wiring diagram:

5.Transaction Information
MOQ	500pcs
Sea Port	Shanghai
Payment Terms	TT prepayment
Supply Ability	500,000pcs of energy meter per month
Delivery time	20-25 days
Normal Package	white box or colorful box for electric energy hour

If you are interested in our Three phase electric energy meter, pls feel free to contact us at any time.
