VV22 PVC Insulated And Sheathed Armored Power Cable STA Armour
Application:
It applies to electrical power transmission and distribution lines with AC rated voltage UO/U up to and including 0.6/1KV. For outdoor and indoor installation in damp and wet locations, laid directly in the ground where excessive mechanical stresses are present in sloping and moving terrains and in vertical or inclined laying, as well as in locations susceptible to sliding.
Specifications:
1. Type: NYY,VV,VV22
2. Voltage rate:0.6/1KV
3. Range of Nominal cross section: 1.5mm2~630mm2
4.Standard: IEC60502,BS7870,GB/T12706
5. Conductors:
conductor:Class 1/2 annealed bare copper solid or srrands
Insulation and sheath:PVC
6. Max operating temperature : 70°C, can be 90°C,110°C as per requirement
Technical Data Sheet:
