Networking cable, computer cable, Cat6 LAN cable , These cables are used by horizontal subsystem in the LAN premises distribution system, being used for the cabling connection between the communication outlet terminal of the system working area and the distributing frame of cross connection closet. The cable is laid in cable gland cable conduit and ceiling or floor interlayer, to make the cable support the application of voice, data, text, image, video, etc.
General Information:
Type : Cat3, Cat5, Cat5e, Cat6 LAN cable
Max. transmission frequency: Cat3: 16MHz; Cat5: 100MHz; Cat5e: 100MHz and support the duplex application; Cat6: 250MHz
Pairs: 2~50 pairs, 2 pairs and 4 pairs is mostly supplied
Conductor size (solid bare copper): Cat3: 0.50mm; Cat5: 0.50mm; Cat5e: 0.52mm; Cat6: 0.60mm
Main manufacturing procedure:
1. Copper wire drawing and annealing
2. Copper wire stranding
3. HDPE insulation extruding
4. PVC sheath extruding
5. Spooling
MAIN QUALITY INSPECTION EQUIPMENT
Sparker tester,Heating aging Chamber,High resistance machine, Oxygen index equipment, Partial dischargeinspection instruments, Fireproof testing device,High-power voltage withstand tester,No-rotor Vulkameter,Pull tester,Analytical balance,Direct current bridge,Plastic tester,Projector, Punch machine,
Cross-linkedcutting machine,etc.
COMPANY OVERVIEW:
PRODUCTION WORKSHOP:
CERTIFICATES:
