2016 Newest Cost-effective Rotogravure Printing Machine with Slitter Blades
Printing material
PVDC |
35-60micron |
PET |
12-60micron |
OPP |
20-60micron |
BOPP |
15-60micron |
PE |
30-100micron |
Nylon |
12-50micron |
CPP |
25-60micron |
Composite film |
15-60micron |
Cellophane |
20-30micron |
PVC |
30-60micron |
Paper |
30-80gsm |
|
|
Main parameter | |
Direction |
From unwind to rewind |
Printing colour |
4 |
Max printing width |
800mm |
Max machinery speed |
100m/min |
Max printing speed |
10-80m/min |
Diameter of printing cylinder |
Φ120mm-Φ300mm |
Precision of register |
Vertical ±0.12mm(Auto ) Horizontal ±0.15mm(Manual) |
Max.Dia.of unwinding&rewinding |
ø650mm |
Air Supply |
0.8Mpa |
Tension Range |
5-30Kg |
Tension Precision |
±0.3Kg |
Machine Overall Dimensions |
15500x3200x3000mm |
Machine Weight |
About 7.2Ton |
Electrics |
CHNT brand |
Motors |
Gongtai brand in Shanghai |
Pneumatic Element |
From Kaogeer Element Co. |
Inverter |
Huichuan brand from Shenzhen |
Machine Structure & support plate |
Alloy casting of high strength and low stress |
Packaging
1- We provide 24 hours call service-- 0086-18815155383
2- We can provide you skillfull knowlege on the machines.
3- Our engineers are available to install and test your machines at any time if requested by the customers.
4- All machines will be examined and tested before shipment.
5- All of our machines are with CE certification.
6- We have already exported to Vietnam, India,Indonesia,Kenya,Egypt,Russia,Turkey etc.
7- Guarantee: 1 year, long life service.
