Taiwan Quality T-shirt Bag Making Machine supplier
1- It is applied to produce printed or non-printed vest bags, with HDPE, LDPE roll film.
2-It adopts PLC control, double step (servo) motor fixed length and touch screen actual display to finish the feeding, sealing, cutting, punching holes and transporting only in one process.
3- It's traced by 2 photocells to make the printing very exact.
4- This machine can save man-power greatly and yield good economic result. It’s the ideal machine for plastic shopping bag purpose.
Model |
DFR-400×2 |
DFR-500×2 |
Max. Bag-making Width |
350mm×2 |
450mm×2 |
Max. Bag-making Length |
500-600 mm×2 |
500-600 mm×2 |
Bag-making thickness |
0.01-0.05 mm |
0.01-0.05mm |
Max.Bag-making Speed |
200-250(pcs/min)×2 |
200-250(pcs/min)×2 |
Air pressure |
7.5Kg/cm2 |
6Kg/cm2 |
Main Power |
8.5kw |
6kw |
Weight |
1400kg |
1500kg |
Overall Dimensions(L X W X H) |
7000X1550X1700mm |
6000×1500×1600mm |
Main Components: | ||
Parts |
Original place |
|
|
Step motor orServo motor |
Made-in-China Or Anchuan from Japan |
2 pcs |
Computer Controller |
Made in Wuxi |
1 set |
Temperature controller |
Yatai, Shanghai |
3 pcs |
Photoeye |
Yatai,Shanghai |
2 pcs |
Main inverter |
Huifeng brand,Yintai, |
1 pc |
DC motor unwinding part |
Deli brand,Wuhu |
2 pcs |
Transferring belts for waste |
Made-in-China |
1 set |
PLC |
Mitsubishi |
1 set |
Pressure cylinder |
Made-in-China |
2 sets |
Some of free spares: | |
Feed spring |
20 pieces |
Thermal board |
2 pcs |
Thermal pipe |
2pcs |
Cutting blade |
2 pcs |
Adhesive tape |
2 pcs |
Tool box |
1 box |
Hammer |
1 set |
Test pen |
1 pc |
Sharp mouth pincer |
1 pc |
Inner hexagonal spanner |
1 pc |
Moving spanner |
8 inch |
Opening spanner 8-10mm/ 12-14 mm/17-19mm ( diameter) |
1 pc |
Heater electric line |
2 pc |
Temperature controller |
1 pc |
1- We provide 24 hours call service-- 0086-18815155383
2- We can provide you skillfull knowlege on the machines.
3- Our engineers are available to install and test your machines at any time if requested by the customers.
4- All machines will be examined and tested before shipment.
5- All of our machines are with CE certification.
6- We have already exported to Vietnam, India,Indonesia,Kenya,Egypt,Russia,Turkey etc.
7- Guarantee: 1 year, long life service.
W are specializing in producing kinds of plastic packaging machines for more than 10 years. We owes excelllent technician,sales and service team. Our achines have been popular with customers from all of the world. Both old and new customers are warmly welcome to visit us! Let's work together! Let's share the same sunshine!
