gold washer trommel

Name: gold washer trommel
Brand: Heng An
Availability: InStock

FOB Price

USD $1,000 - $65,000 / Unit

1 Unit(Min.Order)

Supply Ability 5 Unit / Units per Month
Port Qingdao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	Heng An
Model Number	HATJ100 200	Condition	New
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

1. gold washer trommel

This Gold Trommel Wash Plant is easy to move, even if move it in Jungle.

The plant use gravity principle, whip and wash raw material in scrubber and trommel. It fixed all negative factor caused by high mud percent. The plant can be adjust in gold mine site, based on ore and field.

The machine is 4.7-5.2 meter high, need excavator to load material. The capacity is 300-500 ton per hour.

Water consumption is 350-600 ton per hour.

2. Parameter Of Gold Mining Drilling Equipment

Main Parameter
Model	HATJ-100	HATJ-200
Performance

Dimension (LWH) (mm)	830024004200	980030005175
Processing Capacity (t/h)	100-300	300-500
Main Power

Diesel engine	Weichai	Weichai
Power	50kw	75kw
Trommel Screen

Size (dia*length)	1500x4500mm	2000x5000mm
Power	15kw	30kw
Screen material	20CrMo	20CrMo
Feeder hopper

Size (LWH)	300022001800mm	3800*3000mm
Water system

Pump Power	22kw	30kw
Water flow	224m3/h	240m3/h
Head	27.8m	32m
Optional equipment

Grizzly, Conveyor, Sluice, Concentrator etc.

Heng An Mobile Gold Trommel Wash Plant is a land removable gold mining equipment. It’s high integrated, unitary, easy control, big capacity, stable working, easy maintain, and easy moving.Our engineer can go oversea to install our plant.

3. Small Gold Mining Drilling Equipment

20-30 ton/h, 30-50 ton/h, 50-70 ton/h, 100-140 ton/h Gold Trommel Wash Plant.Small Gold Trommel Wash

Plant, Low Investment, High output.We customized gold trommel wash plant for clients.

4.Mini Gold Mining Drilling Equipment

5~10 ton/h trommel. Manual load material. Use a gasoline to provide power.

Low fuel consumption. Hot sale in Sudan, Zimbabwe, Ghana and other Africa countries.
