DC to DC Converter Boost Buck Step Up Step Down Module Constant Current Voltage
Negotiable
MOQ: 20 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Model Number:
U016V
Type:
Voltage Regulator
Brand Name:
Geree
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen/HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DC Converter Boost 10-32V to 12-35V 150W Step Up Voltage Module MAX 6ANegotiableMOQ: 10 Pieces -
DC 3-30V to 4-35V Boost Converter Voltage Adjustable Module LM2577NegotiableMOQ: 10 Pieces
-
DC3V to 5V 1A USB Charger Boost Module for Phone IphoneNegotiableMOQ: 20 Pieces
-
DC 3V-32V to 5V-35V 4A Dc-dc Buck Converter Step Down ModuleUS$ 0.9 - 1.2MOQ: 20 Pieces
-
DC to DC Converter Module Boost 10-32V to 12V -35V 150W Step Up Voltage MAX 10ANegotiableMOQ: 20 Pieces
Model Number
U016V
Type
Voltage Regulator
Brand Name
Geree
Place of Origin
Guangdong, China
Specifications
DC to DC Converter Boost Buck Step Up Step Down Module constant current voltageConverter Boost Buck Step Up Step Down Voltage Module
step-down constant current, constant voltage module
-
Description
- This module power output is affect by the module itself-capacity and pre-and post-class load and other factors; the following data for professional equipment measured results, without considering other factors.
- Power supply module is a kind of electronic components, please don't buy the item if you have no electronic expertise.
- This Module Properties: It is non-isolated step-down constant current, constant voltage module (CC CV) charging module
Specification:
- Input Voltage :4-35V
- Output voltage: Continuously adjustable(1.25-25V unload adjust)
- Output current:Max 3A(If more than 15W, please install the heat sink)
- Revolving light current: CC value * (1%-100%), default is 0.1 times
- Minimum voltage gap: 2V
- Output power: natural cooling 15W
- Conversion efficiency: 80% (the higher the output voltage, the higher the efficiency)
- Operating Temperature: Industrial (-40 °C to +85 °C) (ambient temperature more than 40°C, lower power use, or add heat sink)
- Full load temperature rise: 45 °C
- Indicator: CC indicator is Red, charging indicator is Red, charging completed the indicator is Blue.
- Output short circuit protection: Yes, constant current.
- Connect method: Can solder on the PCB with wire directly
- Input: IN+ input Positive is, IN- input negative
- Output: OUT+ output is positive, OUT- output negative
- Module Size: 50 x 37 x 13mm
Some Applications:
- High-power LED constant current driver.
- Lithium batteries (including ferroelectric), 4V, 6V, 12V, 14V, 24V battery charging,nickel-cadmium nickel-metal hydride batteries (battery) charge.
- Solar panels, wind generator voltage regulator circuit board power supply, such as automatic buck regulator circuit.
